Kaco blueplanet 3.0 TL3 M2 WM OD IIG0 Operating Instructions

4 Technical data
4.1 Electrical data
KACO
blue-
planet
3.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
4.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
5.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
6.5 TL3
M2 WM
OD IIG0
KACO
blue-
planet
7.5 TL3
M2 WM
OD IIG0
KACO
blue-
planet
8.6 TL3
M2 WM
OD IIG0 -
3TL301
KACO
blue-
planet
9.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
10.0 TL3
M2 WM
OD IIG0 -
3TL301
DC Input levels Input levels (DC)
Recommended generator power
range
3.6 kW 4.8 kW 6 kW 7.8 kW 9 kW 10.3 kW 10.8 kW 12 kW
MPPrange@Pnom 200-800 V
240-800
V
310-800
V
350-800
V
403-800
V
420 - 800
V
470-800
V
Working range 200 V - 950 V
Rated voltage 653 V
Starting voltage 250 V
Open circuit voltage 1,000 V
Max. input current
2
2 x 11 A
Number of strings 1
Number of MPP controls 2
Max. short-circuit current (ISC
max.)
2 x 16 A
Input source feedback current 0 A
Polarity safeguard yes
String fuse no
DC overvoltage protection Built-in
KACO
blue-
planet
3.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
4.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
5.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
6.5 TL3
M2 WM
OD IIG0
KACO
blue-
planet
7.5 TL3
M2 WM
OD IIG0
KACO
blue-
planet
8.6 TL3
M2 WM
OD IIG0 -
3TL301
KACO
blue-
planet
9.0 TL3
M2 WM
OD IIG0
KACO
blue-
planet
10.0 TL3
M2 WM
OD IIG0 -
3TL301
AC Output levels Output levels (AC)
Nominal power 3 kVA 4 kVA 5 kVA 6.5 kVA 7.5 kVA 8.6 kVA 9 kVA 10 kVA
Rated voltage
220 / 380 V [3/N/PE];
230 / 400 V [3/N/PE];
240 / 415 V [3/N/PE]
Voltage range: continuous opera-
tion
305 V - 480 V [Ph-Ph]
2
The "Max. input current" is the maximal theoretical value during operation at full power and minimal MPP voltage.
The inverter will clip to the maximum AC power output.
The "Max. short-circuit current (ISCmax.)" defines together with open circuit voltage (Uocmax) the characteristic of
the connected PV generator. This is the relevant value for string sizing and is the absolute maximal limit for inverter
protection. The connected PV-Generator must be designed, that the max short circuit current is below or equal to
ISCmax of the inverter under all foreseeable conditions. In no condition the design may result in a greater short cir-
cuit current than ISCmax of the inverter.Designing the PV generator [See section7.5.4
}Page22].
KACO blueplanet 3.0 TL3 KACO blueplanet 4.0 TL3 KACO blueplanet 5.0 TL3 KACO blueplanet 6.5 TL3 KACO
blueplanet 7.5 TL3 KACO blueplanet 8.6 TL3 KACO blueplanet 9.0 TL3 KACO blueplanet 10.0 TL3
Page 10
EN
