5 Transportation and Delivery
Every product leaves our factory in perfect electrical and mechanical condition. Special packaging ensures that the
devices are transported safely. The shipping company is responsible for any transport damage that occurs.
5.1 Scope of delivery
 Inverter
 Mount
 Installation kit
 Documentation - EN (quick start guide in other languages)
Check the equipment included
1. Inspect the device thoroughly.
2. Immediately notify the shipping company in case of the following:
– Damage to the packaging that indicates that the device may have been damaged.
– Obvious damage to the device.
3. Send a damage report to the shipping company immediately.
4. The damage report must be received by the shipping company in writing within six days following receipt of the
device. We will be glad to help you if necessary.
5.2 Transporting the device
CAUTION
Hazard due to impact; risk of breakage to the device!
› Pack the device securely for transport.
› Transport the device using the intended carrying handles of the packaging box.
› Do not expose the device to any shocks.
5.3 Installation tool
The codes given in the table below are used in all usage instructions for assembly/installation/maintenance and disas-
sembly for the tools and tightening torques being used.
Code (s) Shape of the
connector
W External hexagon
A Internal hexagon
T Torx
S Slot
Tab.2: Key and description of tool codes
Outer contour
Tightening torque
Spanner size or number
Nm
Fig.2: Form pattern
6 Assembly and preparation
6.1 Choosing the installation location
DANGER
Risk of fatal injury due to fire or explosions!
Fire caused by flammable or explosive materials in the vicinity of the device can lead to serious injuries.
› Do not mount the inverter in potentially explosive atmospheres or in the vicinity of highly flammable
materials.
KACO blueplanet 3.0 TL3 KACO blueplanet 4.0 TL3 KACO blueplanet 5.0 TL3 KACO blueplanet 6.5 TL3 KACO
blueplanet 7.5 TL3 KACO blueplanet 8.6 TL3 KACO blueplanet 9.0 TL3 KACO blueplanet 10.0 TL3
Page 13
EN
