Kaco blueplanet 3.0 TL3 M2 WM OD IIG0 Operating Instructions

KACO
blue-
planet 3.0
TL3 M2
WM OD
IIG0
KACO
blue-
planet 4.0
TL3 M2
WM OD
IIG0
KACO
blue-
planet 5.0
TL3 M2
WM OD
IIG0
KACO
blue-
planet 6.5
TL3 M2
WM OD
IIG0
KACO
blue-
planet 7.5
TL3 M2
WM OD
IIG0
KACO
blue-
planet 8.6
TL3 M2
WM OD
IIG0 -
3TL301
KACO
blue-
planet 9.0
TL3 M2
WM OD
IIG0
KACO
blue-
planet
10.0 TL3
M2 WM
OD IIG0 -
3TL301
General Data
Display Graphical display + LEDs
Controls 4-way button + 2 buttons
Menu languages DE; EN; FR; IT; ES; PL; NL; PT; CZ; HU; SL; TR; RO
Interfaces Standard: 2 x Ethernet, USB, RS485, optional: S0, 4-DI, 4-DO
Communication TCP/IP, Modbus TCP, Sunspec
Potential-free relay Potential-free NO contact, max. 30V/1A DC
DC isolator switch yes
AC isolator switch no
Cooling Fan
Number of fans 1
Noise emission < 53 db(A)
Housing material Aluminium / plastic
HxWxD 522 mm x 363 mm x 246 mm
Weight 30 kg
Certifications Overview: see homepage / download area
4.3 Environmental data
KACO
blue-
planet 3.0
TL3 M2
WM OD
IIG0
KACO
blue-
planet 4.0
TL3 M2
WM OD
IIG0
KACO
blue-
planet 5.0
TL3 M2
WM OD
IIG0
KACO
blue-
planet 6.5
TL3 M2
WM OD
IIG0
KACO
blue-
planet 7.5
TL3 M2
WM OD
IIG0
KACO
blue-
planet 8.6
TL3 M2
WM OD
IIG0 -
3TL301
KACO
blue-
planet 9.0
TL3 M2
WM OD
IIG0
KACO
blue-
planet
10.0 TL3
M2 WM
OD IIG0 -
3TL301
Installation height 3,000m
Installation distance from coast >2000 m
Ambient temperature -25 °C - 60 °C
Power derating from 40 °C
Protection rating (KACO installa-
tion location)
IP65 / NEMA 4
Humidity range (non-condens-
ing) [%]
100%
KACO blueplanet 3.0 TL3 KACO blueplanet 4.0 TL3 KACO blueplanet 5.0 TL3 KACO blueplanet 6.5 TL3 KACO
blueplanet 7.5 TL3 KACO blueplanet 8.6 TL3 KACO blueplanet 9.0 TL3 KACO blueplanet 10.0 TL3
