22 TECHNICAL DATA 180
Screw plug, oil channel M10x1 15 Nm (11.1 lbf ft)
Loctite
®
243™
Screw plug, oil channel, for oil radiator M10x1 15 Nm (11.1 lbf ft) –
Screw, unlocking of timing chain ten-
sioner
M10x1 10 Nm (7.4 lbf ft) –
Spark plug M12x1.25 18 Nm (13.3 lbf ft) –
Coolant temperature sensor on cylinder
head
M12x1.5 12 Nm (8.9 lbf ft) –
Oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft) –
Oil pressure regulator valve plug M12x1.5 20 Nm (14.8 lbf ft) –
Screw plug, oil channel M14x1.5 15 Nm (11.1 lbf ft)
Loctite
®
243™
Engine case stud M16x1.5 25 Nm (18.4 lbf ft)
Loctite
®
243™
Rotor nut M18x1.5 100 Nm (73.8 lbf ft) –
Nut, engine sprocket M20x1.5 80 Nm (59 lbf ft)
Loctite
®
243™
Nut, inner clutch hub M20x1.5 100 Nm (73.8 lbf ft)
Loctite
®
243™
Nut, primary gear M20LHx1.5 90 Nm (66.4 lbf ft)
Loctite
®
243™
Plug, oil screen M20x1.5 15 Nm (11.1 lbf ft) –
Plug, timing chain tensioner M20x1.5 25 Nm (18.4 lbf ft) –
Plug, oil thermostat M24x1.5 15 Nm (11.1 lbf ft) –
Screw in alternator cover M24x1.5 8 Nm (5.9 lbf ft) –
22.4 Capacities
22.4.1 Engine oil
Engine oil 1.70 l (1.8 qt.) Engine oil (SAE 10W/60) (00062010035) ( p. 210)
Alternative engine oil Engine oil (SAE 10W/50)
( p. 210)
22.4.2 Coolant
Coolant 1.20 l (1.27 qt.) Coolant ( p. 210)
Coolant (mixed ready to use) ( p. 210)
22.4.3 Fuel
Total fuel tank capacity,
approx.
12 l (3.2 US gal) Super unleaded (ROZ 95/RON 95/PON 91) ( p. 211)
Fuel reserve, approx. 2.5 l (2.6 qt.)
22.5 Chassis
Frame Lattice frame made of chrome molybdenum steel tubing,
powder-coated
Fork WP Suspension 4860 MXMA
Shock absorber WP Suspension 4618 with Pro‑Lever deflector
Suspension travel
Front 250 mm (9.84 in)
Rear 250 mm (9.84 in)
Brake system
Front Disc brake with dual-piston brake caliper, floating
Rear Disc brake with single-piston brake caliper, floating
Brake discs - diameter
Front 300 mm (11.81 in)
Rear 240 mm (9.45 in)
Brake discs - wear limit
Front 4.5 mm (0.177 in)
