8 FRAME 36

8.1 Removing the engine guard

202021-10

– Remove screws 1 on the left and right.

– Pull the engine guard forward out of the holders and set it down.

8.2 Installing the engine guard

202021-11

– Slide the engine guard into holders 1 at the rear.

– Position the engine guard. Mount and tighten screws 2.

Guideline

Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
