22 TECHNICAL DATA 181
Rear 3.5 mm (0.138 in)
Tire air pressure, road, solo
Front 1.8 bar (26 psi)
Rear 1.8 bar (26 psi)
Tire air pressure with passenger / fully loaded
Front 2.0 bar (29 psi)
Rear 2.2 bar (32 psi)
Tire air pressure, offroad, single rider
Front 1.5 bar (22 psi)
Rear 1.5 bar (22 psi)
Secondary drive ratio 15:45
Chain 5/8 x 1/4” X‑ring
Steering head angle 63°
Wheelbase 1,504±15 mm (59.21±0.59 in)
Seat height unloaded 935 mm (36.81 in)
Ground clearance unloaded 280 mm (11.02 in)
Weight without fuel, approx. 142 kg (313 lb.)
Maximum permissible front axle load 150 kg (331 lb.)
Maximum permissible rear axle load 200 kg (441 lb.)
Maximum permissible overall weight 350 kg (772 lb.)
22.6 Electrical system
Battery YTZ10S Battery voltage: 12 V
Nominal capacity: 8.6 Ah
maintenance-free
Fuse 58011109130 30 A
Fuse 75011088015 15 A
Fuse 75011088010 10 A
Headlight H4 / socket P43t 12 V
60/55 W
Parking light W5W / socket W2.1x9.5d 12 V
5 W
Instrument lights and indicator lamps LED
Turn signal (690 Enduro R EU/AUS/UK) R10W / socket BA15s 12 V
10 W
Turn signal (690 Enduro R USA) RY10W / socket BAU15s 12 V
10 W
Brake/tail light
(690 Enduro R EU/AUS/UK)
LED
Brake/tail light (690 Enduro R USA) P21/5W / socket BAY15d 12 V
21/5 W
License plate lamp W5W / socket W2.1x9.5d 12 V
5 W
22.7 Tires
Validity Front tires Rear tires Condition
(690 Enduro R EU/AUS/UK) 90/90 - 21 M/C 54S M+S TT
Continental TKC 80
140/80 - 18 M/C 70R M+S TT
Continental TKC 80
To max.: 160 km/h
(99.4 mph)
(690 Enduro R USA) 90/90 - 21 M/C 54R TT
Pirelli MT 21 RALLYCROSS
140/80 - 18 M/C 70R TT
Pirelli MT 21 RALLYCROSS
Additional information is available in the Service section under:
http://www.ktm.com
