10.1 Removing the manifold
Warning
Danger of burns The exhaust system gets very hot when the vehicle is driven.
– Allow the exhaust system to cool down. Do not touch hot components.
Preparatory work
– Remove the seat. ( p. 62)
– Take off the side cover. ( p. 63)
202031-10
Main work
– Remove cable binders 1.
– Push the cable to the right. Unplug connector 2 of the lambda sensor.
– Feed out the cable of the lambda sensor.
202032-10
– Remove screws 3.
– Remove the heat guard.
202033-10
– Remove nuts 4 of the manifold.
Info
Do not misplace the spacer.
202034-10
– Loosen screw 5.
– Take off the manifold.
10.2 Installing the manifold
202033-11
Main work
– Position the manifold with the seals.
– Position the spacer.
– Mount and tighten nuts 1.
Guideline
Nut, manifold on cylinder
head
M8 20 Nm
(14.8 lbf ft)
Copper paste
