12. COOLING SYSTEM
12-17
DINK50/ 125
Install the impeller onto the water pump
shaft.
Torque: 1.2 kgf-m (12 N-m, 9 lbf-ft)
Install the two dowel pins and a new gasket.
Install the water pump cover and tighten the
4 bolts.
Torque: 1 kgf-m (10 N-m, 7 lbf-ft)
Impeller (Left Hand Threads)
Dowel Pins
Water Pump Cove
r
Bol
t
The impeller has left hand threads.
＊
Gaske
t
