13. FUEL SYSTEM/CARBURETOR/
FUEL PUMP/ FUEL TANK
13-22
DINK 50/125
FUEL PUMP
REMOVAL/INSTALLATION
Remove the body cover (refer to the
“FRAME COVERS
REMOVAL/INSTALLATION” section in
the chapter 2).
Disconnect the fuel pump inlet hose (2),
outlet hose (1) and vacuum hose (3).
Remove the two nuts and the fuel pump.
Installation is in the reverse order of
removal.
TESTING
Measure the fuel pump output.
Start the engine and disconnect the fuel
outlet tube and place a clean container under
the tube to check the fuel output.
Output: 80cc/1800rpm/25 seconds .
When removing the fuel pump, do not
allow flames or sparks near the working
area and drain the residual gasoline into a
container.
