1. GENERAL INFORMATION
1-30
DINK 50/125
CABLE & HARNESS ROUTING (DINK 50)
Rear Brake Switch
Rear Brake Cable
Front Brake Switch
Front Brake Cable
Throttle Cable
Horn
Resisto
r
Ignition Switch
Connector
Speedometer Cable
Regulator/Rectifie
r
