17. IGNITION SYSTEM
17-5
DINK 50/125
IGNITION PULSE GENERATOR
INSPECTION
Remove the luggage box (refer to the
“FRAME COVERS
REMOVAL/INSTALLATION” section in
the chapter 2).
Disconnect the ignition pulse generator
connector (1).
Measure the ignition pulse generator
resistance between the Green/White wire and
Blue/Yellow wire.
Standard: 106Ω (20ºC/68ºF)
IGNITION COIL
REMOVAL/INSTALLATION
Remove the luggage box (refer to the
“FRAME COVERS
REMOVAL/INSTALLATION” section in
the chapter 2).
Disconnect the spark plug cap from the spark
plug (1).
