2. EXHAUST MUFFLER/FRAME COVERS
2-11
DINK 50/125
Disconnect the rear combination light
connector.
Installation is in the reverse order of removal.
REAR COMBINATION LIGHT UNDER
COVER
Remove body cover (see page 2-10).
Remove the two bolts and rear combination
light under cover.
Installation is in the reverse order of removal.
FLOORBOARD
Remove the body cover (see page 2-10).
Remove the front lower cover (see page 2-
10).
Remove the two screws.
Rear Combination Light Connecto
To Next Page
