14.HANDLEBAR/FRONT WHEEL/FRONT BRAKE/
FRONT SHOCK ABSORBER/STEERING STEM
14-17
DINK 50/125
Install new pads so that their ends rest on the
pad retainer on the brake properly.
Install the pad pin by pushing the pads
against the pad spring to align the pad pin
holes in the pads and caliper.
Install the front caliper onto the fork leg and
then install and tighten the new two caliper
mounting bolts to the specified torque.
Torque: 27 N-m (2.7 kgf-m, 19 lbf-ft)
Tighten the two pad pins to the specified
torque.
Torque: 18 N-m (1.8 kgf-m, 13 lbf-ft)
