9.2.4 Further process data
The parameters listed in the following can also be mapped to network registers, in order to
transmit control and status informaon as well as setpoints and actual values as process data.
Details
•
The following parameters are always available irrespecve of the network opon.
•
The use of these parameters for the transmission of process data is oponal. It is also pos-
sible to only use a part of the parameters. For the transmission of the frequency setpoint
and actual value, for instance, several parameters with a dierent resoluon can be selec-
ted.
•
Via the parameters, at the same me the general network acvity can be diagnosed.
NetWordIN1 ... NetWordIN5
These mappable data words are provided to individually control the inverter:
Data word Parameter Intended use
NetWordIN1 0x4008:001 (P590.01) For implemenng an individual control word format.
4General network sengs ^ 173
NetWordIN2 0x4008:002 (P590.02) For controlling the digital outputs via network.
4Conguraon of digital outputs ^ 415
NetWordIN3 0x4008:003 (P590.03) For controlling the analog outputs via network.
4Conguraon of analog outputs ^ 422
NetWordIN4 0x4008:004 (P590.04)
NetWordIN5 0x4008:005 (P550.05) For dening an addive voltage impression via network.
4Addive voltage impression ^ 323
NetWordOUT1 and NetWordOUT2
These mappable data words are provided to output status messages to the network master:
Data word Parameter Intended use
NetWordOUT1 0x400A:001 (P591.01) For implemenng an individual status word format.
4NetWordOUT1 status word ^ 419
NetWordOUT2 0x400A:002 (P591.02) For the output of messages of the "sequencer" funcon.
4Segment conguraon ^ 327
The following describes all further process data.
Conguring the network
Predened process data words
Further process data
