Parameter Name / value range / [default seng] Info
0x403A:001 ...
0x403A:016
(P855.01 ... 16)
Sequence 6: Step 1 ... Step 16
(Sequence 6: Step 1 ... Step 16)
Conguraon of the steps 1 ... 16 for sequence 6.
•
Alternavely to calling a single segment, a complete sequence (with a
higher number) can also be called from one step. This, for instance,
serves to congure a main sequence from which several subsequen-
ces are called successively.
•
With the seng "0", the respecve step is skipped.
-8 Sequence 8
-7 Sequence 7
0 Skip step
1 Segment 1
2 Segment 2
3 Segment 3
4 Segment 4
5 Segment 5
6 Segment 6
7 Segment 7
8 Segment 8
0x403B
(P856.00)
Number of cycles sequence 6
(Cycl. sequence 6)
1 ... [1] ... 65535
•
From version 03.00
Denion of how oen the sequence 6 is to be passed through.
•
1 = one pass, 2 = two passes, ...
•
65535 = innite number of cycles.
0x403C:001 ...
0x403C:016
(P860.01 ... 16)
Sequence 7: Step 1 ... Step 16
(Sequence 7: Step 1 ... Step 16)
Conguraon of the steps 1 ... 16 for sequence 7.
•
Alternavely to calling a single segment, a complete sequence (with a
higher number) can also be called from one step. This, for instance,
serves to congure a main sequence from which several subsequen-
ces are called successively.
•
With the seng "0", the respecve step is skipped.
-8 Sequence 8
0 Skip step
1 Segment 1
2 Segment 2
3 Segment 3
4 Segment 4
5 Segment 5
6 Segment 6
7 Segment 7
8 Segment 8
0x403D
(P861.00)
Number of cycles sequence 7
(Cycl. sequence 7)
1 ... [1] ... 65535
•
From version 03.00
Denion of how oen the sequence 7 is to be passed through.
•
1 = one pass, 2 = two passes, ...
•
65535 = innite number of cycles.
0x403E:001 ...
0x403E:016
(P865.01 ... 16)
Sequence 8: Step 1 ... Step 16
(Sequence 8: Step 1 ... Step 16)
Conguraon of the steps 1 ... 16 for sequence 8.
•
With the seng "0", the respecve step is skipped.
0 Skip step
1 Segment 1
2 Segment 2
3 Segment 3
4 Segment 4
5 Segment 5
6 Segment 6
7 Segment 7
8 Segment 8
0x403F
(P866.00)
Number of cycles sequence 8
(Cycl. sequence 8)
1 ... [1] ... 65535
•
From version 03.00
Denion of how oen the sequence 8 is to be passed through.
•
65535 = innite number of cycles.
Sequencer
Sequence conguraon
340
