Image Optimization 5-67
Parameter Description
IntPoint/
ExtPoint/
Parallel/ Torch/
3-Light/ User 1/
User 2
Reset the lighting mode to the original status.
Copy to
Copy the lighting mode to customized lighting mode “User 1” or
“User 2”
Other Operations
Zoom
Same as in 3D/4D mode.
Rotation
Rol
l t
he trac
kb
al
l to v
iew s
ecti
onal
im
ages as
necess
ary
. R
otate <
M
>,
<PW
>
, <C>
to p
erf
orm ax
ial
rotation or rotate the <4D> knob to adjust the nearest VOI section (cut plane) position.
Comments and Body Marks
Same as in other modes.
5.10.13 Smart FLC (Smart Follicles Calculation)
CAUTION:
Smart FLC result is provided for reference only, not for confirming a diagnosis.
NOTE: Smart FLC is an optional function, and it is not available in Smart 3D mode.
5.10.13.1 Basic Procedures for Smart FLC
1. Acquire necessary 3D/4D data and freeze.
2. Tap [Smart FLC] tab on the touch screen to enter Smart FLC, and the system is in the “Edit ROI”
status ([Edit ROI] button is highlighted in green);
3. Set the position and size of the ROI box.
4. Tap [Calc] on the touch screen.
5. Auto calculation is finished:
Section image (A, B, C) is enclosed with colored lines and the color corresponds to the follicle
in VR window.
3D image (VR);
Results on the right of the screen are displayed in a table.
V: Volume
d1, d2, d3: diameters of the follicle
MD: Follicle Diam
