Mindray DC-90 User Manual

System Preparation 3-7
3.3 Monitor Adjustment
3.3.1 Monitor Position Adjustment
Gently hold the bottom edge of the monitor when adjusting its position.
 Height and displacement adjustment
Move the monitor support arm up or down to adjust the height, back and forth to adjust the
displacement
NOTE:
Take care not to trap your hands when adjusting the monitor up and down.
 Rotate the monitor
The monitor can turn left 90 degrees to the right 150 degrees along with the support arm.
 Tilt the monitor
When positioned vertically, the monitor can be tilted 20° backward and can be tilted forward to
a horizontal position. When transporting or moving the system, keep the monitor in the
horizontal position, as shown below:
