5-98 Image Optimization
The system inserts a red X into each selected box, like
.
3. Select [Display Selected] on the touch screen.
The system displays the selected phases for each selected view side by side.
To display all views for a specific phase:
Select the phase label (for example, Rest).
To display all phases for a specific view:
Select the view label (for example, PLAX).
The system displays all phases for the selected view.
To display a loop in full-screen format:
1. Double-click the loop to display in full-screen format.
2. Double-click the loop again to display the loop in its initial size, select the loop again.
Description of review/WMS mode keys (keys with the same function as in select mode are not
described below):
Key Description
Shuffle
Perform side-by-side comparison of the same views at different stages (PLAX,
PSAX, A4C, A2C at “Rest” compared to PLAX, PSAX, A4C, A2C “Post-Exercise”).
Clips are synchronized.
Selection: On, Off
Under [Shuffle Mode] "Off” status, when you select one stage, all view loops are
displayed on the screen; when you select one view, all loops of the same view in
different stages will be displayed on the screen.
Set [Shuffle Mode] to “Off”, the system will select loops of first two views of the first
two stages to display automatically. If you choose [Shuffle Forward], then loops of
the next two views of the first stages will be displayed. If you click [Shuffle Back],
loops of the first two views in the 3
rd
and 4
th
stage will be displayed.
In the meantime, if you choose one stage, loops of all views under this stage will
be displayed on the screen (4 at most), and choosing one view will lead to loops of
this view in different stages be displayed (4 at most).
Display Selected Displays loops of all the stages and views selected.
5.14.4.2 Wall Motion Scoring
The WMS-Report lists user-assigned wall motion scores and associated data.
The Wall Motion Score (WMS) measurement is an application prepared for assisting in stress echo
semi-quantitative evaluations of abnormalities with left ventricular wall motion or changes in wall
thickness. The left ventricle is divided into segments for scoring to evaluate the degree of abnormality
from the sum of the scores in each segment using the motion of the walls of the entire left ventricle.
You can assign wall motion scores to specific portions within each view (representative loop). You can
also assign a normal wall motion score (WMS) to the currently selected view or to all displayed views.
Two methods of chamber segment division, ASE 16 and ASE 17, are supported. In addition, each
segment has 3 kinds of scoring method: 4, 5 and 7 points. Select through the [Scoring] control on the
touch screen.
To assign a wall motion score (WMS):
1. Select a colored number in the bottom-right area of the screen.
The meanings and colors used in segments are listed in the table below.
Score Meaning Color
To Next Page
