Display & Cine Review 6-5
e) In auto cine review, pressing the knob under [Auto Play] on the touch screen or rolling
the trackball will stop the auto cine review and enter the manual cine review.
f) Click [Jump to First]/[Jump to Last] to review the first or last image.
Tip: you can perform cine review on each image window in the dual/quad splitting mode, and
set the auto review region for each window.
6.4.3 Cine Review in M/PW/CW/TVD Mode
Enter cine review in M/PW/CW/TVD mode and roll the trackball. The cine images are displayed on
the screen one by one.
Roll the trackball to the left. Or under touch screen mapping mode, swipe the touch screen
leftwards. The review progress slider moves to the left, the images move to the right and the earlier
stored images are displayed. Or, roll the trackball to the right (swipe rightwards). The review
progress slider moves to the right, the images move to the left and the recently stored images are
displayed. When you review images to the first or last frame, rolling the trackball further will display
the last or first frame.
The cine progress bar at the bottom of the screen (as shown in the figure below):
Cine review operations are the same as those in 2D mode.
Tips: when replaying the spectrum cine files, the audio is synchronous with image file when the
auto play speed is set 1.
6.4.4 Linked Cine Review
Linked cine review reviews images captured at the same moment.
Dual live mode (B/Color/Power/TVI/TEI)
B+M
B/B Dual liveDuplex mode (B+PW/CW/TVD)
Triplex mode, TVM or CM mode
The frame mark on the time mark of the M/PW image indicates the corresponding 2D image. In
statuses other than dual live status, you can only review images in the currently active window.
ss bar
Frame synchronization mark
