Mitsubishi Q01CPU User Manual

2
SYSTEM CONFIGURATION
2.1 System Configuration
2.1.5 Precaution on system configuration
2 - 40
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
GENERAL SPECIFICATIONS
4
HARDWARE SPECIFICATIONS OF THE CPU MODULE
5
POWER SUPPLY MODULE
6
BASE UNIT AND EXTENSION CABLE
7
MEMORY CARD AND BATTERY
8
CPU MODULE START- UP PROCEDURES
(b) When the High Performance model QCPU or Process CPU is used
* 3: Only High Performance model QCPU whose serial No. (first five digits) is "09012" or later and
Process QCPU whose serial No. (first five digits) is "10042" or later can be used.
* 4: The following number of modules per CPU can be controlled with the CC-Link network parameter
setting by GX Developer.
• The CPU module whose first 5 digits of serial number is "08031" or earlier: Up to four modules
• The CPU module whose first 5 digits of serial number is "08032" or later: Up to eight modules
If the parameters are set up by CC-Link dedicated instructions, the number of modules installed is
not limited.
For the CC-Link system master/local modules whose parameters can be set up by dedicated
instructions, refer to the manual below.
CC-Link System Master/Local Module User's Manual
* 5: This is applicable only when the High Performance model QCPU is used.
* 6: For applicable GOT modules, refer to the following manuals.
• GOT-A900 Series User’s Manual (GT Work2 Version2/GT Designer2
Version2 Compatible Connection System Manual)
• GOT1000 Series Connection Manual
Table2.11 Number of modules loaded
Applicable module Type
Limitation of installable modules
per system
Q series CC-Link IE controller
network module
*3
• QJ71GP21-SX
• QJ71GP21S-SX
Up to 2 modules
Total: Up to 4
modules
Q series MELSECNET/H network
module
• QJ71LP21
• QJ71BR11
• QJ71LP21-25
• QJ71LP21S-25
• QJ71LP21G
• QJ71LP21GE
Up to 4 in total of
PLC to PLC
network and
remote I/O
network modules
Q series Ethernet interface module
• QJ71E71
• QJ71E71-B2
• QJ71E71-B5
• QJ71E71-100
Up to 4 modules
Q series CC-Link system master
local module
• QJ61BT11
• QJ61BT11N
No limit
*4
MELSECNET/MINI-S3 data link
module
*5
• A1SJ71PT32-S3
• A1SJ71T32-S3
No limit
(setting of automatic refresh function
not allowed)
Special function module for the AnS
series
*5
• A1SD51S
• A1SD21-S1
• A1SJ71J92-S3
(When GET/PUT service is
used)
• A1SJ71AP23Q
• A1SJ71AR23Q
• A1SJ71AT23BQ
Up to 6 modules in total
Interrupt module
• A1SI61
*5
One unit only
• QI60 One module only
GOT
GOT-A900 Series
(for bus connection only)
*6
GOT1000 Series
(for bus connection only)
*6
Up to 5 modules
