9 - 2
9.1 Requirements for Conformance to EMC Directive
9.1.1 Standards relevant to the EMC Directive
9
EMC AND LOW VOLTAGE DIRECTIVES
9.1.1 Standards relevant to the EMC Directive
The standards relevant to the EMC Directive are listed in Table9.1.
*1: QP : Quasi-peak value, Mean : Average value
*2: Programmable controller is an open type device (a device designed to be housed inside other equipment) and must be
installed inside a conductive control panel.
The corresponding test has been conducted with the programmable controller installed inside a control panel.
Besides, our programmable controller has been tested with the maximum rated input value of the power supply module
to be used.
Table9.1 Standards relevant to the EMC Directive
Specification Test item Test details Standard value
EN61131-2:
2003
EN61000-4-2
Electrostatic discharge
immunity
*2
Immunity test in which
electrostatic is applied
to the cabinet of the equipment.
8kV Air discharge
4kV Contact discharge
EN61000-4-3
Radiated electromagnetic
field immunity
*2
Immunity test in which electric
fields are irradiated to the
product.
1.4GHz-2.0GHz, 80-1000MHz, 10V/m,
80%AM modulation@1kHz
EN61000-4-4
Electrical fast transient/
burst immunity
*2
Immunity test in which burst
noise is applied to the power
cable and signal line.
AC power cable: 2kV
DC power cable: 2kV
I/O power(DC): 1kV
DC I/O, analog, communication
line(shielded): 1kV
EN61000-4-5
Surge immunity
*2
Immunity test in which burst
noise is applied to the power line
and signal line.
AC power line:
Common mode 2kV, differential
mode 1kV
DC power line:
Common mode 1kV, differential
mode 0.5kV
I/O power(DC):
Common mode 0.5kV, differential
mode 0.5kV
DC I/O, analog, communication (shielded):
Common mode 1kV
EN61000-4-6
Conducted disturbances
immunity
*2
Immunity test in which high
frequency noise is applied to the
power line and signal line.
0.15-80MHz, 80%AM modulation 1kHz,
3Vrms
To Next Page
