6
BASE UNIT AND EXTENSION CABLE
6.2 Extension Cable
6.2.1 Specification Table
6 - 21
1
OVERVIEW
2
SYSTEM
CONFIGURATION
3
GENERAL
SPECIFICATIONS
4
HARDWARE
SPECIFICATIONS OF
THE CPU MODULE
5
POWER SUPPLY
MODULE
6
BASE UNIT AND
EXTENSION CABLE
7
MEMORY CARD AND
BATTERY
8
CPU MODULE START-
UP PROCEDURES
6.2 Extension Cable
The extension cables are connected to transfer signals between a main base unit and an
extension base unit or between extension base units.
For specifications of the extension cables, refer to Section 6.2.1.
6.2.1 Specification Table
POINT
When the extension cables are used in combination, limit the overall distance of
the combined cable to 13.2 m (43.28 ft.).
Table6.26 Extension cable specifications
Item
Type
QC05B QC06B QC12B QC30B QC50B QC100B
Cable length 0.45m 0.6m 1.2m 3.0m 5.0m 10.0m
Conductor resistance value
0.044 0.051 0.082 0.172 0.273 0.530
Weight 0.15kg 0.16kg 0.22kg 0.40kg 0.60kg 1.11kg
To Next Page
