CPU MODULE START-UP PROCEDURES
CHAPTER8 CPU MODULE START-UP PROCEDURES
This chapter describes the procedures for starting up the Q Series CPU Module.
It is assumed that programs and parameters have been created separately.
For the start-up procedures for a redundant system configured with a Redundant CPU,
refer to the manual below.
QnPRHCPU User's Manual (Redundant System)
Module installation
• • • CHAPTER 10
Install any of the following modules required for the system configuration to the
base unit.
•Power supply module
•CPU module (Install a memory card if necessary.)
•Intelligent function module and/or special function module
•Network module
•I/O module
Wiring/connection
• • • CHAPTER 6,
CHAPTER 7,
CHAPTER 10
1) Wire the power supply to the power supply module.
2) Wire external device(s) to intelligent function module(s), special function
module(s), and/or I/O module(s).
3) Install wiring between network modules.
4) Connect the battery to the CPU module.
5) Connect the main base unit to an extension base unit and between extension
base units with extension cables, and make setting on the number of stages of
extension base units.
Module initialization
• • • CHAPTER 4
1) Halt the CPU module.
2) Set up switches of the intelligent function module(s) and/or special function
module(s).
3) Set up switches of the network module.
System power supply ON
• • • CHAPTER 4,
CHAPTER 5,
CHAPTER 10
Confirm the following items of the system, and then power up the system.
•Wiring of the power supply
•Power supply voltage
•Operating status of the CPU module: Stop status (reset canceled)
Connection of the PC in which GX Developer was installed
• • • GX Developer
Operating
Manual
1) Start up GX Developer on the personal computer.
2) Connect the personal computer with GX Developer installed, to the CPU
module.
Diagram 8.1 CPU module start-up procedures
Start
(To next page)
To Next Page
