12 - 54
12.3 Error Code List
12.3.1 Error codes
12
TROUBLESHOOTING
12.3 Error Code List
The Q series CPU module uses the self diagnostics function to display error information
(on the LED) and stores the information into the special relay SM and special register SD,
when an error occurs in the following situations:
• When the programmable controller is powered ON.
• When the CPU module is switched from STOP to RUN.
• While the CPU module is running.
If an error occurs when a communication request is issued from GX Developer, intelligent
function module or network system to the CPU module, the CPU module returns the error
code (4000
H
to 4FFF
H
) to the request source.
12.3.1 Error codes
Errors are detected by the self diagnostic function of the CPU module or detected during
communication with the CPU module.
The relation between the error detection pattern, error detection location and error code is
shown in Table12.4.
* 1: CPU module error codes are classified into minor, moderate, major errors as shown below.
• Minor error: Errors that may allow the CPU module to continue the operation, e.g., battery
error.
• Moderate error: Errors that may cause the CPU module to stop the operation, e.g., WDT error.
(Error code: 1300 to 10000)
• Major error: Errors that may cause the CPU module to stop the operation, e.g., RAM error.
(Error code: 1000 to 1299)
* 2: When detected an error code without being noted in the reference table, please contact your local
Mitsubishi representive.
Table12.4 Reference destination
Error detection pattern
Error detection
location
Error code Reference
Detection by the self
diagnostics function of
CPU module
CPU module
1000 to 10000
*1*2
Section 12.3.3 to Section 12.3.9
Detection at
communication with CPU
module
CPU module 4000H to 4FFF
H Section 12.3.11
Serial communication
module, etc.
7000H to 7FFF
H
Serial Communication User’s
Manual, etc.
CC-Link module B000H to BFFF
H
CC-Link System Master/Local
Module User’s Manual
Ethernet module C000H to CFFF
H
Ethernet Interface Module User’s
Manual
CC-Link IE controller
network module
E000H to EFFF
H
CC-Link IE Controller Network
System Reference Manual
MELSECNET/H
network module
F000H to FFFF
H
For Q Corresponding MELSECNET/
H Network System Reference
Manual
