7.1.2 Memory Card Specifications
The specifications of the memory card which can be used on the CPU module conform to
those of the PCMCIA small PC card.
(1) SRAM card
(2) Flash card
(3) ATA card
* 1: As for ATA card whose manufacturer control number is E or earlier, capacity after format is as
follows
Manufacturer contrl number E: Q2MEM-8MBA: 7948k bytes, Q2MEM-16MBA: 15948k bytes
Manufacturer control number D or earlier: Q2MEM-8MBA: 7940k bytes, Q2MEM-16MBA: 15932k
bytes
For the manufacturer control number, refer to "POINT" in this section.
* 2: The number of storable files is 511 for a Universal model QCPU.
Table7.2 SRAM card specifications
Item
Type
Q2MEM-1MBS Q2MEM-2MBS Q3MEM-4MBS Q3MEM-8MBS
Memory capacity after format 1011.5 kbyte 2034 kbyte 4078 kbyte 8172 kbyte
Storable number of files 255 287 319
Number of insertions and extractions 5000 times
External dimensions
H 45mm (1.77 inch) 74mm (2.91 inch)
W 42.8mm (1.69 inch)
D 3.3mm (0.13 inch) 8.1mm (0.32 inch)
Weight 15g 30g 31g
Table7.3 Flash card specifications
Item
Type
Q2MEM-2MBF Q2MEM-4MBF
Memory capacity 2035 kbyte 4079 kbyte
Storable number of files 288
Number of insertions and extractions 5000 times
Number of writings 100000 times
External dimensions
H 45mm (1.77 inch)
W 42.8mm (1.69 inch)
D 3.3mm (0.13 inch)
Weight 15g
Table7.4 ATA card specifications
Item
Type
Q2MEM-8MBA Q2MEM-16MBA Q2MEM-32MBA
Memory capacity after format
7982 kbyte
*1
15982 kbyte
*1
31854 kbyte
Storable number of files 512
Number of insertions and extractions 5000 times
Number of writings 1000000 times
External dimensions
H 45mm (1.77 inch)
W 42.8mm (1.69 inch)
D 3.3mm (0.13 inch)
Weight 15g
