Motorola ASTRO Digital Spectra User Manual

7-2 Schematics, Component Location Diagrams and Parts Lists: RF Section
September 5, 2008 6881076C25-E
7.2 RF Section
HRD6001G/6002G/6011G/6012G VHF Receiver
Front-End Component Location Diagram
7-115
HRE6001B/C,6002C,6003B/C,6004B/C,6011B/
C,6012B,6014B UHF Receiver Front-End Preamp
and Standard Schematics
7-117
HRE6001B/C,6002C,6003B/C,6004B/C,6011B/
C,6012B,6014B UHF Receiver Front-End Hybrid
Component Location Diagram
7-118
HRF6004B/C 800 MHz Receiver Front-End
Schematic Diagram
7-121
HRF6004B/C 800 MHz Receiver Front-End
Component Location Diagram
7-122
HLD6022C VHF 50-Watt PA Schematic 7-124
HLD6022C VHF 50-Watt PA Component Location
Diagram, Side 1
7-125
HLD6022C VHF 50-Watt PA Component Location
Diagram, Side 2
7-126
HLD6064C VHF Range 1 and HLD6063D Range 2
100-Watt PA Schematic
7-128
HLD6064C VHF Range 1 and HLD6063D Range 2
100-Watt PA Component Location Diagram, Side 1
7-129
HLD6064C VHF Range 1 and HLD6063D Range 2
100-Watt PA Component Location Diagram, Side 2
7-130
HLD6032B/HLD6066B VHF 25-Watt PA Schematic 7-132
HLD6032B/HLD6066B VHF 25-Watt PA Component
Location Diagram, Side 1
7-133
HLD6032B/HLD6066B VHF 25-Watt PA Component
Location Diagram, Side 2
7-134
HLE6062B and HLE6071B UHF 25-Watt PA
Schematic
7-137
HLE6062B UHF 25-Watt PA Component Location
Diagram, Side 1
7-138
HLE6062B UHF 25-Watt PA Component Location
Diagram, Side 2
7-139
HLE6043C/D, HLE6044C/D, and HLE6049B/C UHF
40-Watt PA Schematic
7-141
HLE6043C/D, HLE6044C/D, and HLE6049B/C UHF
40-Watt PA Component Location Diagram, Side 1
7-142
HLE6043C/D, HLE6044C/D, and HLE6049B/C UHF
40-Watt PA Component Location Diagram, Side 2
7-143
HLE6039C, HLE6040C, and HLE6051C UHF 100-
Watt PA Schematic
7-147
HLE6039C, HLE6040C, and HLE6051C UHF 100-
Watt PA Component Location Diagram, Side 1
7-148
Table 7-1. List of Schematics and Component Location
Diagrams (Continued)
Figure Title Page
HLE6039C, HLE6040C, and HLE6051C UHF 100-
Watt PA Component Location Diagram, Side 2
7-149
HLF6078B 800 MHz 15-Watt PA Schematic 7-154
HLF6078B 800 MHz 15-Watt PA Component
Location Diagram, Side 1
7-155
HLF6078B 800 MHz 15-Watt PA Component
Location Diagram, Side 2
7-156
HLF6077D 800 MHz 35-Watt PA Schematic 7-158
HLF6077D 800 MHz 35-Watt PA Component
Location Diagram, Side 1
7-159
HLF6077D 800 MHz 35-Watt PA Component
Location Diagram, Side 2
7-160
Table 7-2. J500 Command Board to RF Board
J500
Pin #
Description
To
RF Board
1 SW +5V J500B-1
2 REF TUNE J500B-2
3 DOUT* J500B-3
4 DOUT J500B-4
5 SBI J500B-5
6 N/C J500B-6
7 ODC J500B-7
8 GND J500B-8
9 GND J500B-9
10 SW +9.6V J500B-10
11 MOD OUT J500B-11
12 A+ J500B-12
13 GND J500B-13
14 LOCK DET* J500B-14
15 KEYED +9.4V J500B-15
16 ROSC/PSC_CE* J500B-16
17 REF MOD J500B-17
18 MOSI J500B-18
19 SCLK J500B-19
20 SYN SEL* J500B-20
Table 7-1. List of Schematics and Component Location
Diagrams (Continued)
Figure Title Page
21 N/C J500B-21
22 GND J500B-22
23 GND J500B-23
24 GND J500B-24
Table 7-3. P502 Command Board to Control Head
Interconnect Board
P502
Pin #
Description
To
Intcon Board
1SW +9.6V N/C
2 PTT*/P RESET N/C
3 EMERGENCY N/C
4SPARE 2 N/C
5 DISC AUDIO 2 N/C
6 N/C J103-27
7GND J103-3
8 VRS RX AUDIO N/C
9 BUSY J103-25
10 GND N/C
11 LH RESET J103-23
12 VRS TX AUDIO N/C
13 DISC AUDIO N/C
14 VIP OUT 1 J103-8
15 P RS DATA J103-21
16 BOOT/VPP J103-20
17 VO 2 J103-19
18 VO 1 J103-18
19 RX/RS232 N/C
20 TX/RS232 N/C
21 IGN SW B+ J103-11
22 BUS- J103-10
23 KEYFAIL*/TX J103-9
24 PTTB/VIP IN 1 N/C
25 BUS+ J103-22
26 CTS/RS232 N/C
27 VIP OUT 2 J103-7
28 GND J103-6
Table 7-2. J500 Command Board to RF Board
J500
Pin #
Description
To
RF Board
29 HUB/BUSY N/C
30 A+ J103-5
31 SW B+ J103-4
32 KEYED SLOT –
33 RTS/RS232 N/C
34 SPEAKER LOW N/C
35 SPEAKER HIGH N/C
36 UNSW +5V N/C
37 SW +5V N/C
38 VIP IN 2 N/C
Table 7-4. P503 Command Board to RF Power Amplifier
Board
P503
Pin #
Description
To
RF PA
Board
1 CONT VOLT LIMIT P853-2
2 CONT VOLT DRIVE P853-3
3 CURRENT SENSE + P853-4
4 KEYED +9.4V P853-5
5 A+ P853-6
6 TEMP SENSE P853-7
7 KEYED SLOT P853-8
8 FWD DET VOLT P853-9
9 A+ P853-10
10 SW +9.6V P853-11
11 CURRENT SENSE- P853-12
12 GND J2-8
13 MIC HI/RESET/
RTS RS232
J2-15
14 SPEAKER LOW J2-7
15 BUS+ J2-14
16 SPEAKER HIGH J2-6
17 PTT*/TX RS232 J2-13
18 IGN/SW B+ J2-5
19 V_OUT 1 J2-12
20 SW B+ J2-4
Table 7-3. P502 Command Board to Control Head
Interconnect Board (Continued)
P502
Pin #
Description
To
Intcon Board
