Motorola ASTRO Digital Spectra User Manual

6881076C25-E September 5, 2008
Model Numbering, Charts, and Specifications xxxvii
ASTRO Digital Spectra Plus UHF 20–40 Watt Model Chart
Model Number Description
D04QKH9SW3AN Model W3 (403–433 MHz), 20–40 Watt, 512 Channels
D04QKF9SW4AN Model W4 (403–433 MHz), 20–40 Watt, 512 Channels
D04QKF9SW5AN Model W5 (403–433 MHz), 20–40 Watt, 512 Channels
D04QKH9SW7AN Model W7 (403–433 MHz), 20–40 Watt, 512 Channels
T04QKH9SW9AN Model W9 (403–433 MHz), 20–40 Watt, 512 Channels
D04RKH9SW3AN Model W3 (450–482 MHz), 20–40 Watt, 512 Channels
D04RKF9SW4AN Model W4 (450–482 MHz), 20–40 Watt, 512 Channels
D04RKF9SW5AN Model W5 (450–482 MHz), 20–40 Watt, 512 Channels
D04RKH9SW7AN Model W7 (450–482 MHz), 20–40 Watt, 512 Channels
T04RKH9SW9AN Model W9 (450–482 MHz), 20–40 Watt, 512 Channels
Item No. Description
X XXXX HRE6001_ Receiver F/E, Range 1
XXXXX HRE6003_ Receiver F/E, Range 3
X
XXXXXXXXX HRN6020_ RF Board
X
XXXX HLE6045_ VCO Carrier, Range 1
XXXXX HLE6000_ VCO Carrier, Range 3
X
XXXX HLE6101_ VCO Hybrid Kit, Range 1
XXXXX HLE6103_ VCO Hybrid Kit, Range 3
X
XXXXXXXXX HLN5558_ Command Board Kit
X
XXXXXXXXX HLN6837_ VOCODER Controller
X
XXXX HLE6049_ Power Amplifier, 40W, Range 1
XXXXX HLE6043_ Power Amplifier, 40W, Range 3
X X HLN6344_ Interface Board
XXX X XX HLN6401_ Control Head Interconnect Board
X
X HLN6459_ W3 Interface Board
X
X HMN4044_ ASTRO Handheld Control Head (W3)
X X AAHN4045_ Control Head Assembly (W4)
X X XX HLN6396_ Control Head Deck Compatible
X X HCN1078_ W9 Control Head
O
OOOOOOOOO NTN9801_ UCM, ASTRO Spectra Plus
XXX X XX HMN1080_ Microphone
X X HMN1061_ Microphone
X
XXXXXXXXX HSN4018_ Speaker
X X HLN4921_ Trunnion
X X HLN5488_ Installation Hardware
X X HLN6185_* Remote-Mount, SECURENET Control-Head Hardware
X
XXX XXXX HLN6015_ Trunnion/Hardware (Dash Mount)
X
XXX XXXX HLN6073_ Dash-Mount Hardware
X
XXXXXXXXX HLN6418_* Transceiver Hardware
X X HLN6440_* Control Head without Keypad Hardware
X X HLN6441_* Control Head with Keypad Hardware
X X HLN6493_* Plug Kit
X X HLN4952_ Fuse Kit
X
XXX XXXX HKN4191_ Power Cable (Length – 20 Feet)
X X HKN4192_ Power Cable (Length – 20 Feet)
X X HKN4356_ Radio Cable (Length – 17 Feet)
X X HLN6481_* Systems 9000 E9 Clear Button Kit
X X HLN6549_* C4 Button Kit
X = Item Included
O = Optional
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
* = kit not available. Order piece parts from the
Customer Care and Services Division.

Motorola ASTRO Digital Spectra Specifications

General

Brand	Motorola
Model	ASTRO Digital Spectra
Category	Radio
Language	English
