xxviii Model Numbering, Charts, and Specifications

ASTRO Digital Spectra VHF 25–50 and 50–110 Watt Model Chart (cont.)

Model Number Description

D04JKH9SW7AN Model W7 (136–162 MHz), 25–50 Watt, 512 Channels

D04KKH9SW3AN Model W3 (146–174 MHz), 25–50 Watt, 512 Channels

D04KKF9SW4AN Model W4 (146–174 MHz), 25–50 Watt, 512 Channels

D04KKF9SW5AN Model W5 (146–174 MHz); 25–50 Watt, 512 Channels

D04KKH9SW7AN Model W7 (146–174 MHz), 25–50 Watt, 512 Channels

T04KKH9SW9AN Model W9 (146–174 MHz), 25–50 Watt, 512 Channels

T04KLH9SW3AN Model W3 (146–174 MHz), 50–110 Watt, 512 Channels

T04KLF9SW4AN Model W4 (146–174 MHz), 50–110 Watt, 512 Channels

T04KLF9SW5AN Model W5 (146–174 MHz), 50–110 Watt, 512 Channels

T04KLH9SW7AN Model W7 (146–174 MHz), 50–110 Watt, 512 Channels

T04KLH9SW9AN Model W9 (146–174 MHz), 50–110 Watt, 512 Channels

Item No. Description

XXXXX HLN6525_* High-Power Transceiver Hardware

X X HLN6493_* Plug Kit

X X XXX HLN4952_ Fuse Kit

X X XXX HKN4356_ Radio Cable (Length –17 Feet)

XXXXX HKN4051_ Cable and Fuse

XXXXX HKN4191_ Power Cable (Length – 20 Feet)

X HKN4192_ Power Cable (Length – 20 Feet)

XXXXX HKN6039_ Cable (Length – 17 Feet)

X X HLN6481_* Systems 9000 E9 Clear Button Kit

X X HLN6549_* C4 Button Kit

X XXXX X XXX HLN6105_ Emergency/Secure/MPL Button Kit

X X HLN6548_* SMARTNET Button Kit

X X X HLN6523_* SMARTNET Button Kit

X X HLN6167_ Option Button Kit

X HLN6459_ W3 Interface Board Kit

X X HMN4044_ ASTRO Handheld Control Head (W3)

X X TLN5277_ Filter Kit

X HKN6096_ Handheld Control Head “Y” Cable Kit

X HLN6291_ Installation Hardware Kit

X HLN6574_ W3 Interconnect Board Kit

X = Item Included

O = Optional item

_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.

* = kit not available. Order piece parts from the Customer Care and Services Division.
