Schematics, Component Location Diagrams and Parts Lists: RF Section 7-19
6881076C25-E September 5, 2008
Command Boards Reference Designator and Part
Number Comparison Chart
The following table lists those reference designators
common to the various command board kits and the part
numbers assigned to those designators for each kit and
version.
HLN5558E/F/G, HLN6529C/D/E, HLN6560C/D/E/F/G/H,
and HLN6562C/D/E/F/G/H Parts List
Ref Des
HLN5558G
Part Number
HLN6529G
Part Number
HLN6560H
Part Number
HLN6562H
Part Number
C512 2311049A40 2311049A40 2311049A54 2311049A40
C562 2113740B65 2113740B65 NOT PLACED NOT PLACED
C571 2105285X01 NOT PLACED 2105285X01 2105285X01
JU500 NOT PLACED NOT PLACED 0611077A01 0611077A01
JU513 NOT PLACED NOT PLACED 0611077A01 0611077A01
JU518 0611077A01 0611077A01 NOT PLACED NOT PLACED
JU519 0611077A01 0611077A01 NOT PLACED 0611077A01
JU521 0611077A01 0611077A01 NOT PLACED NOT PLACED
JU528 NOT PLACED NOT PLACED 0611077A01 NOT PLACED
JU532 NOT PLACED NOT PLACED NOT PLACED 0611077A01
R561 0611077B29 NOT PLACED 0611077B29 NOT PLACED
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
CAPACITOR, Fixed: unless
otherwise stated
C401, 402 2113741N69 0.1µF
C404 2113741N45 .01µF
C405 2113743G21 1µF
C406 2113743G24 2.2µF
C408 2113741N45 .01µF
C412 2113741N69 0.1µF
C413 2113740B57 220pF
C416 2113743G24 2.2µF
C418 2113741N69 0.1µF
C420, 421 2113743G24 2.2µF
C434 2113741N69 0.1µF
C436 2311049J09 3.3µF
C437 2311049J26 10µF
C438 2311049J09 3.3µF
C451, 452 2113743G21 1µF
C453, 454 2113741N69 0.1µF
C455 2113740B57 220pF
C456 2380090M24 10µF
C457, 458 2113741N69 0.1µF
C459 thru 461 2113743G24 2.2µF
C462 2113741B51 .018µF (HLN5558F/G and
HLN6529D/E)
or 2113741N45 .01µF (HLN5558E and
HLN6529C)
C463 2113740B49 100pF (HLN5558E and
HLN6529C)
or 2113740B59 270pF (HLN5558F/G and
HLN6529D/E
C464 2113741N45 .01µF
C465 2113741B61 .047µF (not placed on
HLN5558F/G and HLN6529D/E)
C466 2113743F14 0.47µF
C467 2113741B61 .047µF (Not placed on
HLN5558F/G and HLN6529D/E)
C468 2113743F08 0.22µF
C476 2113740B65 470pF
C478 2113740B65 470pF
C480 2113740B65 470pF
C481 2113741N21 1000pF
C482 2311049C07 100µF
C500, 501 2113743G24 2.2µF
C502 2113740B36 30pF
C503 2113743G21 1µF (Not placed on
HLN5558F/G and HLN6529E)
C504 2113741N21 1000pF
C505 2311049A40 3.3µF
C506, 507 2113743G24 2.2µF
C508 2113743G21 1µF
C509 2113743G24 2.2µF
C510 2113741N69 0.1µF
C511 2113743F16 1µF
C512 2311049A40 3.3µF
C513 2311049A03 0.22µF
C524 2113741N45 .01µF
C527 2113741N69 0.1µF
C535 2113741N45 .01µF
C548 2113743G21 1µF
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
C549 2113741N69 0.1µF
C554 2113740B65 470pF
C560 2311049A40 2.2µF
C561 thru 565 2113740B65 470pF
C569, 570 2113740B65 470pF
C571 2105285X01 0.47F (Not placed on
HLN6529C/D/E)
C572 2113740B65 470pF
C575 thru 577 2113740B65 470pF
C580 2113741N69 0.1µF
C581 thru 583 2113740B65 470pF
C584 – Not Placed
C585 2113740B65 470pF
C586 thru 589 2113743G24 2.2µF
C591 2113740B36 30pF
C592 2113740B65 470pF
C801 2113741N69 0.1µF
C802 thru 804 2113740B65 470pF
C805 2113741N69 0.1µF
C806 2113740B65 470pF
C807 2113741N69 0.1µF
C808, 809 2113740B65 470pF
C811 2113740B65 470pF
C813 2113741N69 0.1µF
C814 2113740B65 470pF
C815 2113741N69 0.1µF
C816, 817 2113740B65 470pF
C818 2113741N69 0.1µF
C819 2113743G21 1µF
C820 thru 822 2113740B65 470pF
C860 thru 877 2113740B65 470pF
ITEM
MOTOROLA
PART NUMBER
DESCRIPTION
DIODE: See Note 1.
CR400 4813833C10
CR401 4813833C03 Dual
CR402 – Not Placed
CR403 4813833C10
CR500, 501 4813833C10
CR502 – Not Placed
CR503 4813833C10
CR504 – Not Placed
FUSE:
F500 6505663R06 7A
JACK:
J500 0980104M02 Receptacle, Bottom Entry
JUMPER:
JU500, 501 – Not Placed
JU505 – Not Placed
JU508 thru 511 – Not Placed
JU512 0611077A01 0Ω
JU513 – Not Placed
JU514 0611077A01 0Ω
JU515 thru 517 – Not Placed
JU518 thru 521 0611077A01 0Ω
JU523 thru 527 0611077A01 0Ω
JU528 – Not Placed
JU529 thru 531 0611077A01 0Ω
JU532 – Not Placed
JU533 0611077A01 0Ω
ITEM
MOTOROLA
PART N UMBER
DESCRIPTION
To Next Page
