Motorola ASTRO Digital Spectra User Manual

6881076C25-E September 5, 2008
Model Numbering, Charts, and Specifications xxxix
ASTRO Digital Spectra Plus UHF 50–110 Watt Model Chart
Model Number Description
T04QLH9SW3AN Model W3 (403–433 MHz), 50–110 Watt, 512 Channels
T04QLF9SW4AN Model W4 (403–433 MHz), 50–110 Watt, 512 Channels
T04QLF9SW5AN Model W5 (403–433 MHz), 50–110 Watt, 512 Channels
T04QLH9SW7AN Model W7 (403–433 MHz), 50–110 Watt, 512 Channels
T04QLH9SW9AN Model W9 (403–433 MHz), 50–110 Watt, 512 Channels
T04RLH9SW3AN Model W3 (450–482 MHz), 50–110 Watt, 512 Channels
T04RLF9SW4AN Model W4 (450–482 MHz), 50–110 Watt, 512 Channels
T04RLF9SW5AN Model W5 (450–482 MHz), 50–110 Watt, 512 Channels
T04RLH9SW7AN Model W7 (450–482 MHz), 50–110 Watt, 512 Channels
T04RLH9SW9AN Model W9 (450–482 MHz), 50–110 Watt, 512 Channels
T04SLH9SW3AN Model W3 (482–512 MHz), 50–110 Watt, 512 Channels
T04SLF9SW4AN Model W4 (482–512 MHz), 50–110 Watt, 512 Channels
T04SLF9SW5AN Model W5 (482–512 MHz), 50–110 Watt, 512 Channels
T04SLH9SW7AN Model W7 (482–512 MHz), 50–110 Watt, 512 Channels
T04SLH9SW9AN Model W9 (482–512 MHz), 50–110 Watt, 512 Channels
Item No. Description
XXXXX HRE6001_ Board, RX Front-End, Range 1
XXXXX HRE6003_ Board, RX Front-End, Range 3
X XXXX HRE6004_ Board, RX Front-End, Range 4
XX
XXXXXXXXXXXXX HRN6020_ RF Board
XX
XXX HLE6045_ VCO Carrier, Range 1
XXXXX HLE6039_ VCO Carrier, Range 3
X XXXX HLE6041_ VCO Carrier, Range 4
XX
XXX HLE6101_ VCO Hybrid Kit, Range 1
XXXXX HLE6103_ VCO Hybrid Kit, Range 3
X XXXX HLE6104_ VCO Hybrid Kit, Range 4
XX
XXXXXXXXXXXXX HLN5558_ Command Board Kit
XX
XXXXXXXXXXXXX HLN6837_ VOCON Board Kit
XX
XXX HLE6051_ Power Amplifier Board, 100W, Range 1
XXXXX HLE6099_ Power Amplifier Board, Range 3
X XXXX HLE6040_ Power Amplifier Board, Range 4
X
XXX XXXX XXXX HLN6486_ Interconnect Board
X
X X HLN6574_ W3 Interconnect Board
X
XX XXX XXX HLN6432_ Back Housing, Control Head
X
X X HMN4044_ W3 Handheld Control Head
X
X X AAHN4045_ Control Head Assembly (W4)
XX X X XX HLN6396_ W5, W7 Control Head Board
X X X HCN1078_ W9 Control Head
OO
OOOOOOOOOOOOO NTN9801_ UCM, ASTRO Spectra Plus
X
XX XXX XXX HMN1080_ Microphone
X X X HMN1061_ Microphone
XX
XXXXXXXXXXXXX HSN6001_ Speaker
X X X HLN4921_ Control Head (W9) Trunnion
O O O HLN5488_ Radio Microphone Installation Hardware
X
XX XXX XXX HLN6231_ Remote W4, W5, W7 Control-Head Trunnion
XX
XXXXXXXXXXXXX HLN6233_* Option Connector Hardware
XX
XXXXXXXXXXXXX HLN6132_* Installation Hardware, High-Power
X
X X HLN6291_ Installation Hardware Kit
XX
XXXXXXXXXXXXX HLN6121_* High-Power Radio Hardware
XX
XXXXXXXXXXXXX HLN6525_* High-Power Transceiver Hardware
X = Item Included
O = Optional
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
* = kit not available. Order piece parts from the Customer Care and Services Division.
