Motorola ASTRO Digital Spectra User Manual

September 5, 2008 6881076C25-E
xlii Model Numbering, Charts, and Specifications
ASTRO Digital Spectra Plus 800 MHz Model Chart (cont.)
Model Number Description
M04UGF9SW4AN Model W4 (800 MHz), 15 Watt, 512 Channels
M04UGF9SW5AN Model W5 (800 MHz), 15 Watt, 512 Channels
M04UGH9SW7AN Model W7 (800 MHz), 15 Watt, 512 Channels
D04UJH9SW3AN Model W3 (800 MHz), 35 Watt, 512 Channels
D04UJF9SW4AN Model W4 (800 MHz), 35 Watt, 512 Channels
D04UJF9SW5AN Model W5 (800 MHz), 35 Watt, 512 Channels
D04UJH9SW7AN Model W7 (800 MHz), 35 Watt, 512 Channels
T04UJH9SW9AN Model W9 (800 MHz), 35 Watt, 512 Channels
Item No. Description
X HLN6440_* W5 Control Head without Keypad Hardware
X HLN6444_* Hardware, Control Head, Motorcycle
X HLN6441_* W7 Control Head with Keypad Hardware
X HLN6445_* Control Head, Motorcycle Hardware
X X HLN6493_* Large Black Plug Kit
X HLN4952_ Fuse Kit
XXXX HKN4191_ Power Cable (Length – 20 Feet)
OOOOX HKN4192_ Power Cable (Length – 20 Feet)
O OOX HKN4356_ Remote Mount Radio Cable (Length – 17 Feet)
X
XX HKN6062_ Cable, Control Head to Radio
X
XX HKN6032_ Motorcycle Power Cable
X
XX X XXX HLN6105_ Spare Button Kit
X
XX X XXX HLN6688_ Phon/Page/Emer/MPL Button
X
XX X XXX HLN6645_ Emergency/MPL Field Option Button Kit
X HLN6549_* W4 Button Kit
X X HLN6548_* SMARTNET Button Kit
X HLN6208_ Button, Spectra SECURENET
X X HLN6523_* SMARTNET Button Kit
X HLN6167_ Option Button Kit
X HLN6481_* Systems 9000 E9 Clear Button Kit
X HLN6675_* System 9000 Button Kit Secure
X HLN6249_* Button, Secure
X X HLN6524_ Button, Conventional
XXXXX RRA4914_ Antenna, 1/4-Wave
X
XX RAF4011_ 800 MHz Antenna, 3 dB Gain
X = Item Included
O = Optional
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
* = kit not available. Order piece parts from the Customer Care and Services Division.
