Motorola ASTRO Digital Spectra User Manual

6881076C25-E September 5, 2008
Model Numbering, Charts, and Specifications xli
ASTRO Digital Spectra Plus 800 MHz Model Chart
Model Number Description
M04UGF9SW4AN Model W4 (800 MHz), 15 Watt, 512 Channels
M04UGF9SW5AN Model W5 (800 MHz), 15 Watt, 512 Channels
M04UGH9SW7AN Model W7 (800 MHz), 15 Watt, 512 Channels
D04UJH9SW3AN Model W3 (800 MHz), 35 Watt, 512 Channels
D04UJF9SW4AN Model W4 (800 MHz), 35 Watt, 512 Channels
D04UJF9SW5AN Model W5 (800 MHz), 35 Watt, 512 Channels
D04UJH9SW7AN Model W7 (800 MHz), 35 Watt, 512 Channels
T04UJH9SW9AN Model W9 (800 MHz), 35 Watt, 512 Channels
Item No. Description
X XXXXXXX HRF6004_ Receiver Kit, Front-End
X
XXXXXXX HRN6019_ RF Board Kit
X
XXXXXXX HLF6080_ VCO Carrier
X
XXXXXXX HLF6079_ VCO Hybrid
XXXXX HLN5558_ Command Board Kit
X
XX HLN6562_ Command Board, Motorcycle
X
XXXXXXX HLN6837_ Vocoder/Controller
XXXXX HLF6077_ Power Amplifier
X
XX HLF6078_ 15W, 800 MHz Power Amplifier
O OOX HLN6344_ Board, Remote Mount Interconnect
X
XX HLN6365_ Board, Motorcycle Interconnect
X HLN6459_ Board, Interconnect
X XX HLN6401_ Control Head Interconnect Board
O OO HKN6432_ Back Housing Kit
X HMN4044_ Handheld Control Head
X AAHN4045_ Front Housing, W4 Control Head
X
PMLN4019_ W4 ASTRO Motorcycle Control Head
XX HLN6396_ Control Head DEK-Compatible
XX HLN6563_ Motorcycle Control Head
X HCN1078_ W9 Control Head
O
OOOOOOO NTN9801 UCM
X XX HMN1080_ Microphone, Standard
X HMN1061_ Microphone
X
XX HMN1079_ Microphone, Motorcycle, Waterproof
XXXXX HSN4018_ Speaker
X
XX HSN6003_ Speaker, Motorcycle, Waterproof
X
XX HLN6179_ Motorcycle Adapter Control Head Speaker
XXXX HLN6015_ Trunnion/Hardware
X HLN5488_ Installation Hardware (W9 Trunnion)
X HLN4921_ Trunnion, Control Head W9
XOOOX HLN6185_* Remote-Mount, SECURENET Control Head Hardware
X
XXXXXXX HLN6418_* Transceiver Hardware
XXXXX HLN6126_ Mid-Power Dash Mount Radio Hardware
XXXX HLN6073_ Radio Hardware
X HLN6638_ Radio Hardware
X HLN6613_ Transceiver Hardware
X
XX HLN6639_* Radio Hardware
X
XX HLN6180_ Motorcycle Mounting Hardware
X
XX HLN6342_* Motorcycle Hardware, Secure
O OO HLN6231_ Hardware, Remote-Mount Dash
X = Item Included
O = Optional
_ = the latest version kit. When ordering a kit, refer to your specific kit for the suffix number.
* = kit not available. Order piece parts from the Customer Care and Services Division.

Motorola ASTRO Digital Spectra Specifications

General

Brand	Motorola
Model	ASTRO Digital Spectra
Category	Radio
Language	English
