Motorola CDM1250 Service Manual

Section 3: 3-44 Controller T12 Schematics and Parts Lists
6881091C63-F
Controller T12 Parts List
Circuit
Ref
Motorola
Part No.
Description
C0101 2113944C45 100pF
C0107 2113945L25 1000pF
C0112 2113945C31 0.1uF
C0121 2113945C31 0.1uF
C0122 2113945C31 0.1uF
C0131 2113944C34 22pF
C0132 2113944C34 22pF
C0141 2113945C31 0.1uF
C0151 2113945L49 10000pF
C0201 2313960D07 10uF
C0202 2313960D07 10uF
C0204 2113945C31 0.1uF
C0212 2313960D07 10uF
C0221 2113945C31 0.1uF
C0222 2113945C31 0.1uF
C0223 2113945C31
0613952G67
0.1uF
0 ohm (SUB on LS+ Models
Only)
C0224 2113944C45 100pF
C0225 2113945C31 0.1uF
C0226 2113945C31 0.1uF
C0228 2313960B30 4.7uF
C0231 2113955D31 1uF
C0232 2113945C31 0.1uF
C0234 2113945C31 0.1uF
C0235 2113945C04 0.022uF
C0236 2113945C25 0.033uF
C0241 2113945C31 0.1uF
C0243 2113944C45 100pF
C0244 2113945C31 0.1uF
C0245 2113945C31 0.1uF
C0246 2113945L49 10000pF
C0251 2113945C31 0.1uF
C0252 2313960B01 1uF
C0254 2113945C31 0.1uF
C0255 2113945C31 0.1uF
C0256 2113944C45 100pF
C0261 2113945C31 0.1uF
C0262 2113944C43 82pF
C0265 2113945C31 0.1uF
C0267 2113945L49 10000pF
C0271 2113945L49 10000pF
C0272 2113945C31 0.1uF
C0273 2113945L37 3300pF
C0275 2313960F30 47uF
C0276 2113945L25 1000pF
C0277 2113945L25 1000pF
C0421 2113944A38 82pF
C0422 2113945L17 470pF
C0423 2113945L17 470pF
C0426 2113945A05 470pF
C0427 2113945A05 470pF
C0428 2113944A38 82pF
C0429 2113945A05 470pF
C0430 2113945L17 470pF
C0431 2113945L17 470pF
C0441 2113945A05 470pF
C0442 2113945A05 470pF
C0445 2113945A05 470pF
C0446 2113945A05 470pF
C0447 2113945A05 470pF
C0448 2113945A05 470pF
C0449 2113945A05 470pF
C0470 2113945A05 470pF
C0471 2113944A38 82pF
C0472 2113944A38 82pF
C0473 2113944A38 82pF
C0474 2113945A05 470pF
C0476 2113945A05 470pF
C0477 2113945A05 470pF
C0478 2113945A05 470pF
C0482 2113945A05 470pF
C0483 2113945A05 470pF
C0484 2113945L17 470pF
C0485 2113945A05 470pF
C0486 2113945A05 470pF
C0487 2113945A05 470pF
C0488 2113945A05 470pF
C0490 2113945A05 470pF
C0491 2113945A05 470pF
C0492 2113945A05 470pF
C0493 2113945A05 470pF
C0494 2113945A05 470pF
C0495 2113945A05 470pF
C0496 2113945A05 470pF
C0497 2113945A05 470pF
C0499 2113945A05 470pF
C0501 2113945L49 10000pF
C0502 2113945L17 470pF
C0503 2113945L17 470pF
C0504 2113945L17 470pF
C0505 2113945L17 470pF
C0506 2113945L17 470pF
Circuit
Ref
Motorola
Part No.
Description
C0508 2113945L17 470pF
C0509 2113945L17 470pF
C0510 2113945L17 470pF
C0511 2113945L17 470pF
C0512 2113945L17 470pF
C0513 2113945L17 470pF
C0514 2113945L17 470pF
C0515 2113945L17 470pF
C0516 2113945L49 10000pF
C0517 2113944A38 82pF
C0518 2113945L17 470pF
C0541 2313960A55 0.47uF
C0542 2313960F30 47uF
C0560 2113945A09 1000pF
C0591 2113945C31 0.1uF
C0592 2113945C31 0.1uF
C0593 2113945H69
0613958T74
0.1uF
0 ohm (SUB on LS+ Models
Only)
C0601 2113945L17 470pF
C0603 2389289U01 10uF
C0611 2314030J28 22uF
C0612 2113945C31 0.1uF
C0622 2313960F30 47uF
C0641 2113945L17 470pF
C0644 2375194A03 33uF
C0645 2113945C31 0.1uF
C0652 2313960F04 33uF
C0654 2313960D07 10uF
C0655 2113945C31 0.1uF
C0661 2314030H05 47uF
C0662 2113945L49 10000pF
C0663 2113945C31 0.1uF
C0671 2113945C31 0.1uF
C0681 2113945C31 0.1uF
D0101 4813974A05 DIODE 30V HOT CARRIER
D0151 4813978C02 DIODE DUAL 70V
D0179 4813978C02 DIODE DUAL 70V
D0621 4813978C02 DIODE DUAL 70V
D0651 4813978C02 DIODE DUAL 70V
D0660 4813978C02 DIODE DUAL 70V
D0661 4813978C02 DIODE DUAL 70V
E0271 2415954H02 INDUCTOR BEAD CHIP
E0272 2415954H02 INDUCTOR BEAD CHIP
E0631 2415954H02 INDUCTOR BEAD CHIP
F0401 6515076H01 FUSE 3A
J0401 0916162H02 12 PIN CONNECTOR
Circuit
Ref
Motorola
Part No.
Description
J0451 0916162H01 “FLEX CONNECTOR, SIDE”””
J0501 0966512A01 20 PIN CONNECTOR
J0551 0915064H03 40 PIN CONNECTOR
J0552 0915064H01 18 PIN CONNECTOR
J0601 0986165B02 MOBILE DC POWER
Q0110 4813973A42 TSTR NPN
Q0151 4813973A42 TSTR NPN
Q0171 4813973A42 TSTR NPN
Q0173 4816147H01 TSTR NPN
Q0177 4813973A42 TSTR NPN
Q0181 4813973A42 TSTR NPN
Q0183 4813973A42 TSTR NPN
Q0185 4813973A42 TSTR NPN
Q0271 4813973M07 TSTR NPN
Q0641 4813973A42 TSTR NPN
Q0661 4816097H01 XISTOR FMC2 RH
Q0662 4813973M07 TSTR NPN
Q0663 4813973A42 TSTR NPN
Q0681 4816147H01 TSTR NPN
R0101 0613952J01 10K
R0102 0613952H89 4700
R0103 0613952H25 10
R0104 0613952J01 10K
R0105 0613952J25 100K
R0108 0613952H81 2200
R0111 0613952G67 0
R0113 0613952J01 10K
R0114 0613952J01 10K
R0115 0613952J01 10K
R0117 0613952H87 3900
R0121 0613952J25 100K
R0131 0613952J73 10M
R0132 0613952J37 330K
R0151 0613952J10 24K
R0152 0613952J10 24K
R0170 0613952J01 10K
R0171 0613952H89 4700
R0172 0613952J01 10K
R0173 0613952H89 4700
R0174 0613952J01 10K
R0175 0613952J01 10K
R0176 0613952J12 30K
R0177 0613952H89 4700
R0178 0613952J17 47K
R0179 0613952J17 47K
R0181 0613952H89 4700
R0182 0613952J17 47K
Circuit
Ref
Motorola
Part No.
Description
