Section 8: 4-16 VHF (136–174 MHz) 25–45 W Bipolar PCB 8486140B13, Schematics, and Parts Lists
6881091C63-F
VHF 25–45 W PCB 8486140B13 Parts List
†
Circuit
Ref
Motorola
Part No.
Description
C3000 2113741F37 3.3nF 50V
C3001 2113740F19 4.7pF 5%
C3002 2113740F26 9.1pF 5%
C3003 2113741F37 3.3nF 50V
C3004 2113740F45 56pF 5%
C3005 2113740F51 100pF 5%
C3006 2113740F45 56pF 5%
C3007 2113741F37 3.3nF 50V
C3008 2113741F25 1nF 50V
C3009 2113741F13 330pF 50V
C3010 2113741F13 330pF 50V
C3011 2113741F37 3.3nF 50V
C3012 2113741F25 1nF 50V
C3013 2113740F45 56pF 5%
C3014 2113740F24 7.5pF 5%
C3015 2113740F45 56pF 5%
C3016 2113740F51 100pF 5% 50V
C3017 2113740F42 43pF 5% 50V
C3019 2113741F25 1nF 50V
C3020 2113741F25 1nF 50V
C3021 2113740F53 120pF 5% 50V
C3022 2113741F49 10nF 50V
C3026 2113743E20 100nF 16V
C3027 2113741F49 10nF 50V
C3028 2113741F49 10nF 50V
C3030 2113741F25 1nF 50V
C3033 2113740F20 5.1pF 5% 50V
C3034 2113740F49 82pF 5% 50V
C3035 2113740F33 18pF 5% 50V
C3036 2113741F25 1nF 50V
C3100 2113741F25 1nF 50V
C3102 2113740F31 15pF 5% 50V
C3103 2113740F39 33pF 5% 50V
C3104 2113743E20 100nF 16V
C3110 2113740F37 27pF 5% 50V
C3111 2113743E20 100nF 16V
C3112 2113740F49 82pF 5% 50V
C3114 2113740F33 18pF 5% 50V
C3115 2113740F35 22pF 5% 50V
C3116 2113743E20 100nF 16V
C3121 2113743E20 100nF 16V
C3122 2113743E11 39nF 10%
C3123 2113743E11 39nF 10%
C3124 2113740L30
NU
33pF 2% 3rd overtone crystal
fundamental crystal
C3132 2113743E20 100nF 16V
C3133 2311049A57 TANT CP 10uF 10% 16V
C3134 2113743E20 100nF 16V
C3135 2113740L30 33pF 2%
C3136 2113740F35
2113740L29
22pF 3rd overtone crystal
30pF 2% fundamental crystal
C3137 2113743E11 39nF 10%
C3139 2113743E20 100nF 16V
C3140 2113743E20 100nF 16V
C3141 2113743E20 100nF 16V
C3142 2113743E20 100nF 16V
C3143 2113740F53 120pF 5% 50V
C3144 2113743E20 100nF 16V
C3145 2113743E20 100nF 16V
C3146 2113741F41 4.7nF 50V
C3147 2113743E20 100nF 16V
C3151 2113741F49 10nF 50V
C3152 2113741F49 10nF 50V
C3202 2113741F49 10nF 50V
C3203 2113741F49 10nF 50V
C3205 2113741F49 10nF 50V
C3206 2311049A57 TANT CP 10uF 10% 16V
C3208 2113743E20 100nF 16V
C3209 2113743E20 100nF 16V
C3210 2311049A40 TANT CP 2.2uF 10% 10V
C3211 2113743E20 100nF 16V
C3213 2311049A40 TANT CP 2.2uF 10% 10V
C3214 2311049A09 TANT CP 2.2uF 10% 20V
C3215 2311049A09 TANT CP 2.2uF 10% 20V
C3221 2113743E20 100nF 16V
C3222 2113743E20 100nF 16V
C3224 0882422W23 FILM SM 1.0uF 15V 5%
C3225 2113743E20 100nF 16V
C3226 2113740F25 8.2pF 5% 50V
C3227 2113740F51 100pF 5% 50V
C3228 2113743E20 100nF 16V
C3229 2113743E12 47nF 10%
C3231 2113741F49 10nF 50V
C3232 2113741F49 10nF 50V
C3233 2311049A40 TANT CP 2.2uF 10%
C3234 2113741F49 10nF 50V
C3235 2113741F49 10nF 50V
C3242 2113740F59 220pF 5% 50V
C3243 2113740F59 220pF 5% 50V
C3244 2113740F59 220pF 5% 50V
C3245 2113740F59 220pF 5% 50V
C3246 2113740F59 220pF 5% 50V
C3247 2113740F27 10pF 5% 50V
C3251 2113743E20 100nF 16V
C3252 2113741F25 1nF 50V
C3253 2311049A56 TANT CP 4.7uF 20% 10V
C3254 2113743E20 100nF 16V
C3255 2311049A40 TANT CP 2.2uF 10% 10V
C3263 2113743E20 100nF 16V
C3302 2113740F23 6.8pF 5% 50V
Circuit
Ref
Motorola
Part No.
Description
C3303 2113741F49 10nF 50V
C3306 2113740F20 5.1pF 5% 50V
C3311 2113743E07 22nF 16V
C3314 2113740F23 6.8pF 5% 50V
C3315 2113740F31 15pF 5% 50V
C3316 2113740F15 3.3pF 5% 50V
C3317 2113740F39 33pF 5% 50V
C3318 2113740F21 5.6pF 5% 50V
C3319 2113741F25 1nF 50V
C3324 2113741F49 10nF 50V
C3332 2113743E20 100nF 16V
C3333 2113743E20 100nF 16V
C3334 2113743E07 22nF 16V
C3335 2113741F49 10nF 50V
C3336 2113741F49 10nF 50V
C3337 2113743E20 100nF 16V
C3341 2113741F25 1nF 50V
C3342 2113740L05 3.0pF +-0.1pF
C3344 2113740F09 1.8pF 5% 50V
C3345 2113740L25 20pF +-0.25pF
C3346 2113741F49 10nF 50V
C3347 2113741F49 10nF 50V
C3348 2113741F49 10nF 50V
C3351 2113741F49 10nF 50V
C3352 2113743E07 22nF 16V
C3355 2113741F49 10nF 50V
C3356 2113743E07 22nF 16V
C3357 2113740F24 7.5pF 5% 50V
C3361 2113741F25 1nF 50V
C3362 2113740F21 5.6pF 5% 50V
C3363 2113740F47 68pF 5% 50V
C3364 2113740F31 15pF 5% 50V
C3365 2113741F25 1nF 50V
C3400 2113741F33 2.2nF 50V
C3401 2113741F33 2.2nF 50V
C3402 2113743E07 22nF 16V
C3404 2113741F33 2.2nF 50V
C3405 2113740A79 1nF 5% 50V
C3406 2113740A79 1nF 5% 50V
C3407 2113741F33 2.2nF 50V
C3408 2113740F33 18pF 5% 50V
C3409 2113741F33 2.2nF 50V
C3410 2113743E07 22nF 16V
C3411 2113743E07 22nF 16V
C3412 2113741F33 2.2nF 50V
C3413 2113743E07 22nF 16V
C3414 2113741F33 2.2nF 50V
C3415 2113743E07 22nF 16V
C3416 2113741F33 2.2nF 50V
C3417 2113741F33 2.2nF 50V
C3418 2113740F36 24pF 5% 50V
Circuit
Ref
Motorola
Part No.
Description
C3420 2113740F49 82pF 5% 50V
C3421 2113741A45 10nF 50V
C3422 2113740A79 1nF 5% 50V
C3424 2113741A45 10nF 50V
C3425 2113928E01 1uF 10% 10V
C3426 2113741F33 2.2nF 50V
C3428 2113741F33 2.2nF 50V
C3430 2113740A41 33pF 5% 50V
C3431 2113740A61 180pF 5% 50V
C3432 2113740A53 82pF 5% 50V
C3433 2113740A29 10pF 5% 50V
C3434 2113928E01 1uF 10% 10V
C3435 2113741F33 2.2nF 50V
C3436 2311049A45 TANT CP 10uF 10% 35V
C3437 2113741M69 0.1uF 50V
C3439 2113741W01 1uF 10% 25V
C3440 2113741M69 0.1uF 50V
C3441 2113740A79 1nF 5% 50V
C3442 2111078B57 HQ 390pF 5%
C3443 2111078B51 RF 220 5 NPO 100V
C3444 2111078B51 RF 220 5 NPO 100V
C3445 2113740A79 1nF 5% 50V
C3446 2180464E50 56pF 5% 250V
C3447 2180464E50 56pF 5% 250V
C3448 2111078B31 HQ 36pF 5%
C3449 2111078B31 HQ 36pF 5%
C3450 2111078B38 HQ 68pF 5%
C3451 2111078B20 HQ 18pF 5%
C3452 2111078B38 HQ 68pF 5%
C3455 2111078B36 HQ 56pF 5%
C3456 2113740A79 1nF 5% 50V
C3457 2113740A79 1nF 5% 50V
C3458 2113741A45 10nF 50V
C3459 2180464E16 100pF 5% 250V
C3460 2113743E20 100nF 16V
C3461 2113741F33 2.2nF 50V
C3464 2113740F28 11pF 5% 50V
C3465 2113740A79 1nF 5% 50V
C3466 2113740A79 1nF 5% 50V
C3467 2111078B40 HQ 82pF 5%
C3468 2111078B20 HQ 18pF 5%
C3471 2113743E07 22nF 16V
C3472 2111078B47 HQ 150pF 5%
C3473 2111078B47 HQ 150pF 5%
C3474 2113740A79 1nF 5% 50V
C3475 2113740F33 18pF 5% 50V
C3478 2113741F33 2.2nF 50V
C3489 2111078B45 HQ 130pF 5%
C3490 2111078B31 HQ 36pF 5%
C3492 2111078B59 HQ 470pF 5%
C3494 2111078B34 HQ 47pF 5%
Circuit
Ref
Motorola
Part No.
Description
