Motorola CDM1250 Service Manual

UHF Band 1 (403–470 MHz) 25–40 W LDMOS PCB 8471223L02, Schematics, and Parts Lists Section 12: 4-21
6881091C63-F
UHF B1 25–40 W PCB 8471223L02 Parts List
Circuit
Ref
Motorola
Part No.
Description
C3101 2113944C80 CAP 20 PF
C3102 2113944C32 CAP 15 PF
C3103 2113944C36 CAP 33 PF
C3104 2113945C31 CAP 0.1 UF
C3110 2113944C61 CAP 0.5 PF
C3111 2113945C31 CAP 0.1 UF
C3112 2113944C36 CAP 33 PF
C3113 2113944C75 CAP 8.2 PF
C3114 2113944C30 CAP 10 PF
C3115 2113944C32 CAP 15 PF
C3116 2113945C31 CAP 0.1 UF
C3121 2113945C31 CAP 0.1 UF
C3122 2113945C26 CAP 39 UF
C3123 2113945C26 CAP 39 UF
C3124 2113944M30 CAP 33 PF
C3132 2113945C31 CAP 0.1 UF
C3133 2313960D07 CAP 10 UF
C3134 2113945C31 CAP 0.1 UF
C3135 2113944M30 CAP 33 PF
C3136 2113944C34 CAP 22 PF
C3137 2113945C26 CAP 39 UF
C3139 2113945C31 CAP 0.1 UF
C3140 2113945C31 CAP 0.1 UF
C3141 2113945C31 CAP 0.1 UF
C3142 2113945C31 CAP 0.1 UF
C3143 2113944C46 CAP 120 PF
C3144 2113945C31 CAP 0.1 UF
C3145 2113945C31 CAP 0.1 UF
C3146 2113945L41 CAP 4700 PF
C3147 2113945C31 CAP 0.1 UF
C3151 2113945L49 CAP 1 UF
C3152 2113945L49 CAP 1 UF
C4001 2113944C69 CAP 1.8 PF
C4002 2113944C43 CAP 82 PF
C4003 2113944C35 CAP 27 PF
C4004 2113944C36 CAP 33 PF
C4005 2113944C36 CAP 33 PF
C4006 2113944C36 CAP 33 PF
C4007 2113944C82 CAP 30 PF
C4008 2113945L25 CAP 1000 PF
C4009 2113944C30 CAP 10 PF
C4010 2113945L13 CAP 330 PF
C4011 2113945L37 CAP 3300 PF
C4012 2113945L13 CAP 330 PF
C4013 2113945L37 CAP 3300 PF
C4014 2113944C45 CAP 100 PF
C4015 2113944C45 CAP 100 PF
C4017 2113944C69 CAP 1.8 PF
C4018 2113944C80 CAP 20 PF
C4019 2113944C31 CAP 12 PF
C4020 2113944C36 CAP 33 PF
C4021 2113944C36 CAP 33 PF
C4022 2113944C36 CAP 33 PF
C4023 2113944C31 CAP 12 PF
C4024 2113945L25 CAP 1000 PF
C4026 2113944C69 CAP 1.8 PF
C4027 2113944C69 CAP 1.8 PF
C4028 2113945L49 CAP 1 UF
C4029 2113944C69 CAP 1.8 PF
C4030 2113944C69 CAP 1.8 PF
C4031 2113944C78 CAP 13 PF
C4051 2113944C30 CAP 10 PF
C4052 2113944C43 CAP 82 PF
C4053 2113944C79 CAP 16 PF
C4054 2113944C79 CAP 16 PF
C4055 2113944C73 CAP 6.8 PF
C4061 2113944C04 CAP 330 PF
C4062 2113945C31 CAP 0.1 UF
C4064 2113945C31 CAP 0.1 UF
C4065 2113944C45 CAP 100 PF
C4067 2113945L37 CAP 3300 PF
C4068 2113944C45 CAP 100 PF
C4069 2113945L49 CAP 1 UF
C4201 2113944C45 CAP 100 PF
C4202 2113945L49 CAP 1 UF
C4203 2113945L49 CAP 1 UF
C4204 2113944C45 CAP 100 PF
C4205 2113945L49 CAP 1 UF
C4206 2313960F01 CAP 10 UF
C4208 2113945C31 CAP 0.1 UF
C4209 2113945C31 CAP 0.1 UF
C4210 2113946N03 CAP 2.2 UF
C4211 2113945C31 CAP 0.1 UF
C4213 2313960C78 CAP 2.2 UF
C4214 2313960C78 CAP 2.2 UF
C4215 2313960C78 CAP 2.2 UF
C4217 2113945L49 CAP 1 UF
C4221 2113944F13 CAP 1 UF
C4222 2189705V01 CAP 0.1 UF
C4223 2115358H25 CAP 1 UF
C4225 2113945L18 CAP 510 PF
Circuit
Ref
Motorola
Part No.
Description
C4226 2113944M03 CAP 2.4 PF
C4227 2113944C30 CAP 10 PF
C4230 2113946N03 CAP 2.2 UF
C4231 2113945L49 CAP 1 UF
C4232 2113945L49 CAP 1 UF
C4233 2113946N03 CAP 2.2 UF
C4234 2113945L49 CAP 1 UF
C4235 2113945L49 CAP 1 UF
C4236 2113945C27 CAP 47 UF
C4242 2113944C45 CAP 100 PF
C4243 2113944C45 CAP 100 PF
C4244 2113944C45 CAP 100 PF
C4245 2113944C45 CAP 100 PF
C4246 2113944C45 CAP 100 PF
C4251 2113945C31 CAP 0.1 UF
C4252 2113945L25 CAP 1000 PF
C4253 2313960B30 CAP 4.7 UF
C4254 2113945C31 CAP 0.1 UF
C4255 2113944C45 CAP 100 PF
C4263 2113945C31 CAP 0.1 UF
C4287 2113944C45 CAP 100 PF
C4289 2113945C31 CAP 0.1 UF
C4301 2113944C45 CAP 100 PF
C4302 2113944M16 CAP 8.2 PF
C4303 2113944M16 CAP 8.2 PF
C4304 2113944M08 CAP 3.9 PF
C4306 2113944M01 CAP 2 PF
C4307 2113944C45 CAP 100 PF
C4308 2113945C31 CAP 0.1 UF
C4309 2113944C45 CAP 100 PF
C4311 2113944C45 CAP 100 PF
C4312 2113944C31 CAP 12 PF
C4314 2113944C67 CAP 1.5 PF
C4315 2113944C45 CAP 100 PF
C4316 2189705V01 CAP 0.1 UF
C4318 2113945C31 CAP 0.1 UF
C4321 2113944C63 CAP 1 PF
C4324 2113944M03 CAP 2.4 PF
C4325 2313960B30 CAP 4.7 UF
C4331 2113944M14 CAP 6.8 PF
C4335 2113944C45 CAP 100 PF
C4336 2113945C04 CAP 22000 PF
C4337 2113944C85 CAP 51 PF
C4338 2113944C85 CAP 51 PF
C4351 2113944C45 CAP 100 PF
C4352 2113945C31 CAP 0.1 UF
Circuit
Ref
Motorola
Part No.
Description
C4353 2113945C31 CAP 0.1 UF
C4354 2113946N03 CAP 2.2 UF
C4355 2113946N03 CAP 2.2 UF
C4361 2113945L25 CAP 1000 PF
C4364 2113944C71 CAP 5.6 PF
C4365 2113944C67 CAP 1.5 PF
C4371 2113945C31 CAP 0.1 UF
C4401 2113944C45 CAP 100 PF
C4403 2113944C20 CAP 3.9 PF
C4404 2113944C45 CAP 100 PF
C4407 2113945C31 CAP 0.1 UF
C4409 2113945C31 CAP 0.1 UF
C4410 2113944C45 CAP 100 PF
C4412 2113944C45 CAP 100 PF
C4413 2113944C45 CAP 100 PF
C4414 2113945C04 CAP 22000 PF
C4415 2113944C45 CAP 100 PF
C4416 2113945C04 CAP 22000 PF
C4417 2113944C85 CAP 51 PF
C4418 2113945C31 CAP 0.1 UF
C4420 2113944F44 CAP 12 PF
C4421 2113945G57 CAP 33000 PF
C4422 2111078B42 CAP 100 PF
C4424 2113944C38 CAP 56 PF
C4425 2113945C04 CAP 22000 PF
C4426 2113944C45 CAP 100 PF
C4427 2113944F33 CAP 4.3 PF
C4428 2113944F70 CAP 180 PF
C4429 2113944F70 CAP 180 PF
C4431 2113944F52 CAP 27 PF
C4432 2113944F58 CAP 47 PF
C4433 2113944F58 CAP 47 PF
C4434 2113944F33 CAP 4.3 PF
C4435 2113944F44 CAP 12 PF
C4436 2113955E37 CAP 10 UF
C4438 2113945C31 CAP 0.1 UF
C4439 2111078B42 CAP 100 PF
C4440 2111078B25 CAP 27 PF
C4441 2111078B25 CAP 27 PF
C4443 2111078B16 CAP 13 PF
C4445 2111078B16 CAP 13 PF
C4448 2171388L01 CAP 12 PF
C4449 2111078B03 CAP 3.9 PF
C4450 2111078B03 CAP 3.9 PF
C4454 2113944F33 CAP 4.3 PF
C4457 2113944F55 CAP 36 PF
Circuit
Ref
Motorola
Part No.
Description
