Motorola CDM1250 Service Manual

Section 7: 1-2 Low Band Range 2 (36–42 MHz) Model Charts
6881091C63-F
2.0 Low Band Range 2 (36–42 MHz) Model Charts
2.1 CDM Series Model Chart
2.2 PRO Series Model Chart
CDM Series, Low Band Range 2 (36–42 MHz)
Model Description
AAM25CKC9AA1AN CDM750, 36–42 MHz, 40–60 W, 20 kHz
1
AAM25CKD9AA2AN CDM1250, 36–42 MHz, 40–60 W, 20 kHz
1
AAM25CKF9AA5AN CDM1550, 36–42 MHz, 40–60 W, 20 kHz
1
Item Description
X GCN6112 Control Head, CDM750
X GCN6113 Control Head, CDM1250
X GCN6114 Control Head, CDM1550
X X X
IMUB6001 Tanapa, 36–42 MHz, 40–60 W, 20 kHz
1
XXX
IMUB6001_S Replacement Board, 36–42 MHz, 40–60 W, 20 kHz
1
X X X RAB4003_RB Antenna, 36–42 MHz, 1/4 Wave Base Loaded (Mini
U)
X 6881091C54 User Guide, CDM750
X 6881091C55 User Guide, CDM1250
X 6881091C56 User Guide, CDM1550
PRO Series, Low Band Range 2 (36–42 MHz)
Model Description
LAM25CKD9AA2AN PRO5100, 36–42 MHz, 40–60 W, 20 kHz Ch Sp
1
Item Description
X GCN6113 Control Head, PRO5100
X
IMUB6001 Tanapa, 36–42 MHz, 40–60 W, 20 kHz
1
X
IMUB6001_S Replacement Board, 36–42 MHz, 40–60 W, 20 kHz
1
X RAB4003_RB Antenna, 36–42 MHz, 1/4 Wave Base Loaded (Mini U)
X 6881091C58 User Guide, PRO5100

Motorola CDM1250 Specifications

General

Display	Alphanumeric
IP Rating	IP54
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Signaling	PL, DPL, MDC1200, Quick Call II
Operating Temperature	-22°F to +140°F (-30°C to +60°C)
Power Output	VHF: 1-25W; UHF: 1-25W
