Motorola CDM1250 Service Manual

Section 3: 3-18 Controller T5 Schematics and Parts Lists
6881091C63-F
Controller T5 Parts List
Circuit
Ref
Motorola
Part No.
Description
C0101 2113740F51 100pF 5% 50V
C0107 2113741F25 1nF 50V
C0112 2113743E20 100nF 16V
C0121 2113743E20 100nF 16V
C0122 2113743E20 100nF 16V
C0131 2113740F35 22pF 5% 50V
C0132 2113740F35 22pF 5% 50V
C0141 2113743E20 100nF 16V
C0151 2113741F49 10nF 50V
C0201 2311049A57 TANT CP 10uF 10% 16V
C0202 2311049A57 TANT CP 10uF 10% 16V
C0204 2113743E20 100nF 16V
C0212 2311049A57 TANT CP 10uF 10% 16V
C0221 2113743E20 100nF 16V
C0222 2113743E20 100nF 16V
C0223 2113743E20 100nF 16V
C0224 2113740F51 100pF 5% 50V NP0
C0225 2113743E20 100nF 16V
C0226 2113743E20 100nF 16V
C0228 2311049A07 TANT CP 1uF 10% 16V
C0231 2113743B29 1 uF 10% 16V
C0232 2113743E20 100nF 16V
C0234 2113743E20 100nF 16V
C0235 2113743E07 22nF 16V
C0236 2113743E10 .033uF 10%
C0241 2113743E20 100nF 16V
C0243 2113740F51 100pF 5% 50V
C0244 2113743E20 100nF 16V
C0245 2113743E20 100nF 16V
C0246 2113741F49 10nF 50V
C0252 2311049A07 TANT CP 1uF 10%
C0254 2113743E20 100nF 16V
C0255 2113743E20 100nF 16V
C0261 2113743E20 100nF 16V
C0262 2113740F49 82pF 5% 50V
C0265 2113743E20 100nF 16V
C0267 2113741F49 10nF 50V
C0271 2113741F49 10nF 50V
C0272 2113743E20 100nF 16V
C0273 2113741F37 3.3nF 50V
C0275 2311049A99 TANT CP 47uF 20% 10V
C0276 2113741F25 1nF 50V
C0277 2113741F25 1nF 50V
C0301 2311049A07 1uF 10% 16V
Voice storage only
C0302 2113743E20 100nF 16V
Voice storage only
C0303 2113740F51 100pF 5% 50V
Voice storage only
C0304 2113743E20 100nF 16V
Voice storage only
C0305 2113743E20 100nF 16V
Voice storage only
C0324 2113743E20 100nF 16V
Voice storage only
C0331 2113743E20 100nF 16V
Voice storage only
C0341 2311049A07 TANT CP 1uF 10% 16V
Voice storage only
C0342 2113743E20 100nF 16V
Voice storage only
C0343 2113743E20 100nF 16V
Voice storage only
C0344 2113743E20 100nF 16V
Voice storage only
C0351 2113743E20 100nF 16V
Voice storage only
C0352 2113743E07 22nF 16V
Voice storage only
C0353 2311049A97 TANT CHIP 33 uF 16
Voice storage only
C0354 2113743E20 100nF 16V
Voice storage only
C0421 2113743N48 82.0 pF 5%
C0422 2113741F17 470pF 50V
C0423 2113741F17 470pF 50V
C0426 2113743L09 470 pF 10%
C0427 2113743L09 470 pF 10%
C0428 2113743N48 82.0 pF 5%
C0429 2113743L09 470 pF 10%
C0430 2113741F17 470pF 50V
C0431 2113741F17 470pF 50V
C0445 2113743L09 470 pF 10%
C0446 2113743L09 470 pF 10%
C0447 2113743L09 470 pF 10%
C0448 2113743L09 470 pF 10%
C0449 2113743L09 470 pF 10%
C0470 2113743L09 470 pF 10%
C0471 2113743N48 82.0 pF 5%
C0472 2113743N48 82.0 pF 5%
C0473 2113743N48 82.0 pF 5%
C0474 2113743L09 470 pF 10%
C0476 2113743L09 470 pF 10%
C0477 2113743L09 470 pF 10%
Circuit
Ref
Motorola
Part No.
Description
C0478 2113743L09 470 pF 10%
C0482 2113743L09 470 pF 10%
C0483 2113743L09 470 pF 10%
C0484 2113741F17 470 pF 50V
C0485 2113743L09 470 pF 10%
C0486 2113743L09 470 pF 10%
C0487 2113743L09 470 pF 10%
C0488 2113743L09 470 pF 10%
C0490 2113743L09 470 pF 10%
C0491 2113743L09 470 pF 10%
C0492 2113743L09 470 pF 10%
C0493 2113743L09 470 pF 10%
C0494 2113743L09 470 pF 10%
C0495 2113743L09 470 pF 10%
C0496 2113743L09 470 pF 10%
C0497 2113743L09 470 pF 10%
C0499 2113743L09 470 pF 10%
C0501 2113741F49 10nF 50V
C0502 2113743L09 470 pF 10%
C0503 2113743L09 470 pF 10%
C0504 2113743L09 470 pF 10%
C0505 2113743L09 470 pF 10%
C0506 2113743L09 470 pF 10%
C0508 2113743L09 470 pF 10%
C0509 2113743L09 470 pF 10%
C0510 2113741F17 470 pF 50V
C0511 2113743L09 470 pF 10%
C0512 2113743L09 470 pF 10%
C0513 2113741F17 470 pF 50V
C0514 2113743L09 470 pF 10%
C0515 2113743L09 470 pF 10%
C0516 2113741F49 10nF 50V
C0517 2113743N48 82.0 pF 5%
C0518 2113743L09 470 pF 10%
C0541 2311049A05 TANT CP 470nF 10% 25V
C0542 2311049A99 TANT CP 47uF 20% 10V
C0591 2113743E20 100nF 16V
C0592 2113743E20 100nF 16V
C0593 2113741B69 100nF 50V
C0601 2113741F17 470pF 50V
C0603 2380090M24 LYT 10uF 50V 20%
C0611 2311049C06 TANT CP 22uF 20% 35V
C0612 2113743E20 100nF 16V
C0622 2311049A99 TANT CP 47uF 20% 10V
C0641 2113741F17 470pF 50V
C0644 2311049A97 TANT CHIP 33 uF 16
C0645 2113743E20 100nF 16V
Circuit
Ref
Motorola
Part No.
Description
C0652 2311049A97 TANT CHIP 33 uF 16
C0654 2311049A57 TANT CP 10uF 10% 16V
C0655 2113743E20 100nF 16V
C0661 2311049C05 TANT CP 47uF 10% 16V
C0662 2113741F49 10nF 50V
C0663 2113743E20 100nF 16V
C0671 2113743E20 100nF 16V
C0681 2113743E20 100nF 16V
D0101 4880236E05 CHIP SCHOTTKY
D0151 4813833C02 DUAL SOT MMBD6100
D0179 4813833C02 DUAL SOT MMBD6100
D0301 4802245J47 SCHOTTKY BARRIER
(RB471E)
Voice storage only
D0621 4813833C02 DUAL SOT MMBD6100
D0651 4813833C02 DUAL SOT MMBD6100
D0660 4813833C02 DUAL SOT MMBD6100
D0661 4813833C02 DUAL SOT MMBD6100
E0271 2484657R01 Ferrite Bead
E0272 2484657R01 Ferrite Bead
E0631 2484657R01 Ferrite Bead
J0401 0902636Y02 CONN FLEX 12 PIN
J0451 0902636Y01 CONN FLEX SIDE ENTRY
J0501 0986105B01 CONN SMD 20 PIN
J0551 0905505Y04 CONN ZIF HORIZONTAL
J0552 0905505Y03 CONN ZIF 18PIN
J0601 0986165B01 DC PWR CONN
Q0110 4880048M01 NPN DIG 47k/47k
Q0151 4880048M01 NPN DIG 47k/47k
Q0171 4880048M01 NPN DIG 47k/47k
Q0173 4880052M01 NPN DRLNGTN MXTA
Q0177 4880048M01 NPN DIG 47k/47k
Q0181 4880048M01 NPN DIG 47k/47k
Q0183 4880048M01 NPN DIG 47k/47k
Q0185 4880048M01 NPN DIG 47k/47k
Q0271 4813824A10 NPN 40V .2A
Q0641 4880048M01 NPN DIG 47k/47k
Q0661 4805921T02 DUAL ROHM FMC2 RH
Q0662 4813824A10 NPN 40V .2A B=50-150
Q0663 4880048M01 NPN DIG 47k/47k
Q0681 4880052M01 NPN DRLNGTN MXTA
R0101 0662057A73 10k 1/16W 5%
R0102 0662057A65 4700 1/16W 5%
R0104 0662057A73 10k 1/16W 5%
R0105 0662057A97 100k 1/16W
Voice storage only
R0106 0662057B47 0 1/16W
Voice storage only
Circuit
Ref
Motorola
Part No.
Description
