Motorola CDM1250 Service Manual

Section 6: 1-1
6881091C63-F
Chapter 1
MODEL CHARTS AND TECHNICAL SPECIFICATIONS
1.0 UHF Band 2 (450–512/527 MHz) 1–25 W Model Charts
1.1 CDM Series Model Chart
CDM Series, UHF Band 2 (450–512 MHz) 1–25 W
(Conventional, LTR/PassPort)
Model Description
AAM25SHC9AA1AN CDM750, 450–512 MHz, 1–25 W, 12.5/20/25 kHz
AAM25SHD9AA2AN CDM1250, 450–512 MHz, 1–25 W, 12.5/20/25 kHz
AAM25SHF9AA5AN CDM1550, 450–512 MHz, 1–25 W, 12.5/20/25 kHz
AAM25SHF9DU5AN CDM1550•LS, 450–512 MHz, 1–25 W, 12.5/20/25 kHz
AAM25SHF9DP5AN CDM1550•LS
+
, 450–512 MHz, 1–25 W, 12.5/20/25 kHz
Item Description
X GCN6112 Control Head, CDM750
X GCN6113 Control Head, CDM1250
XXX GCN6114 Control Head, CDM1550
XXXX IMUE6028 Tanapa, UHF 450–512 MHz, 1–25 W, 12.5/20/25 kHz
XXXX IMUE6028_S Replacement Board, UHF 450–512 MHz, 1–25 W, 12.5/20/25 kHz
X PMUE1755 Tanapa, CDM1550•LS
+
, 450–512 MHz, 1–25 W
X PMUE1755_S Replacement Board, CDM1550•LS
+
, 450–512 MHz, 1–25 W
XXXXX HAE4003_R Antenna, 450–470 MHz, 1/4 Wave Roof Mount (Mini U)
XXXXX HAE4004 Antenna, 470–512 MHz, 1/4 Wave Roof Mount (Mini U)
XXXXX HAE4011_R Antenna, 450–470 MHz, 3.5dB Gain Roof Mount (Mini U)
XXXXX HAE4012_ Antenna, 470–494 MHz, 3.5dB Gain Roof Mount (Mini-U)
XXXXX HAE4013_ Antenna, 494–512 MHz, 5dB Gain Roof Mount (Mini-U)
X 6881091C54 User Guide, CDM750
X 6881091C55 User Guide, CDM1250
X 6881091C56 User Guide, CDM1550
X 6881093C32 User Guide, CDM1550•LS
X 6881094C79 User Guide, CDM1550•LS+

Motorola CDM1250 Specifications

General

Display	Alphanumeric
IP Rating	IP54
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Signaling	PL, DPL, MDC1200, Quick Call II
Operating Temperature	-22°F to +140°F (-30°C to +60°C)
Power Output	VHF: 1-25W; UHF: 1-25W
