Motorola CDM1250 Service Manual

Section 4: 1-1
6881091C63-F
Chapter 1
MODEL CHARTS AND TECHNICAL SPECIFICATIONS
1.0 VHF (136–174 MHz) 1–25W Model Charts
1.1 CDM Series Model Chart
CDM Series, VHF (136–174 MHz) 1–25W
Model Description
AAM25KHC9AA1AN CDM750, 136–174 MHz, 1–25W, 12.5/20/25 kHz
AAM25KHD9AA2AN CDM1250, 136–174 MHz, 1–25W, 12.5/20/25 kHz
AAM25KHF9AA5AN CDM1550, 136–174 MHz, 1–25W, 12.5/20/25 kHz
AAM25KHF9DP5AN
CDM1550 LS
+
, 136–174 MHz, 25W, 16CH
AAM25KHF9DP6AN
CDM1550 LS
+
, 136–174 MHz, 25W, 160CH w/MDC
Item Description
X GCN6112 Control Head, CDM750
X GCN6113 Control Head, CDM1250
XXX GCN6114 Control Head, CDM1550
XXX IMUD6014 Tanapa, VHF 136–174 MHz, 1–25W, 12.5/20/25 kHz
XXX IMUD6014_S Replacement Board, VHF 136–174 MHz, 1–25W, 12.5/20/25 kHz
X
PMUD 2076A
Tanapa, VHF 136–174 MHz, 25W 16CH
X PMUD 2077A Tanapa, VHF 136–174 MHz, 25W 160CH w/MDC
XXXXX HAD4006 Antenna, 136–144 MHz, 1/4 Wave Roof Mount (Mini U)
XXXXX HAD4007 Antenna, 146–150.8 MHz, 1/4 Wave Roof Mount (Mini U)
XXXXX HAD4008 Antenna, 150.8–162 MHz, 1/4 Wave Roof Mount (Mini U)
XXXXX HAD4009 Antenna, 162–174 MHz, 1/4 Wave Roof Mount (Mini U)
XXXXX HAD4014 Antenna, 146–172 MHz, 3dB Gain Roof Mount (Mini U)
X X X 6881091C54 User Guide, CDM750
X X X 6881091C55 User Guide, CDM1250
X 6881091C56 User Guide, CDM1550
X X 6881094C79
User Guide, CDM1550 LS
+

Motorola CDM1250 Specifications

General

Display	Alphanumeric
IP Rating	IP54
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Signaling	PL, DPL, MDC1200, Quick Call II
Operating Temperature	-22°F to +140°F (-30°C to +60°C)
Power Output	VHF: 1-25W; UHF: 1-25W
