Motorola CDM1250 Service Manual

Section 7: 4-80 Low Band Range 3 (42–50 MHz) PCBs, Schematics, and Parts Lists
6881091C63-F
Low Band R3 PCB 8485908Z02 Parts List
†
Circuit
Ref
Motorola
Part No.
Description
C1001 NOTPLACED
C1002 2113741F49 .01uF
C1003 2113740F50 91pF
C1004 2113740F57 180pF
C1006 2113740F45 56pF
C1007 2113740F57 180pF
C1008 2113740F69 560pF
C1009 2113740F57 180pF
C1010 2113740F42 43pF
C1011 2113740F48 75pF
C1012 2113740F60 240pF
C1013 2113741F21 680pF
C1014 2113740F54 130pF
C1015 2113741F49 .01uF
C1016 2113740F54 130pF
C1017 2113740F67 470pF
C1019 2113740F63 330pF
C1020 2113740F56 160pF
C1021 2113740F65 390pF
C1022 2113740F55 150pF
C1023 2113740F65 390pF
C1024 2113740F56 160pF
C1025 2113740F62 300pF
C1026 2113741F25 1000pF
C1027 2113740F52 110pF
C1028 2113741F49 .01uF
C1029 2113741F49 .01uF
C1030 2113743E20 0.1uF
C1031 2113743E20 0.1uF
C1032 2113740F46 62pF
C1033 2113740F47 68pF
C1034 2113740F48 75pF
C1035 2113740F44 51pF
C1036 2113743E20 0.1uF
C1101 2113740F53 120pF
C1102 2113740F50 91pF
C1103 2113740F58 200pF
C1104 2113743E20 0.1uF
C1105 2113743E20 0.1uF
C1106 2113743E20 0.1uF
C1107 2113740F49 82pF
C1108 2113743E20 0.1uF
C1109 2113740F40 36pF
C1111 2113740L03 2.4pF
C1112 2113740F40 36pF
C1113 2113743E20 0.1uF
C1114 2113743E20 0.1uF
C1115 2113740F53 120pF
C1116 2113740F41 39pF
C1119 2113743E20 0.1uF
C1123 2113740F39 33pF
C1124 2113743E20 0.1uF
C1125 2113743E11 .039uF
C1126 2113743E20 0.1uF
C1127 2311049A57 10uF
C1128 2113743E20 0.1uF
C1129 2113740F35 22pF
C1130 2113740F47 68pF
C1133 2113743E20 0.1uF
C1134 2113743E20 0.1uF
C1135 2113743E20 0.1uF
C1136 2113743E20 0.1uF
C1137 2113740F53 120pF
C1138 2113743E20 0.1uF
C1139 2113741F49 .01uF
C1140 2113741F49 .01uF
C1141 2113743E20 0.1uF
C1142 2113743E20 0.1uF
C1143 2113743E20 0.1uF
C1144 2113743E20 0.1uF
C1145 2113741F41 4700pF
C1146 2113740F49 82pF
C1147 2113740F65 390pF
C1148 2113743E20 0.1uF
C1149 2113740F53 120pF
C1150 2113740F54 130pF
C1201 2113743E20 0.1uF
C1202 2311049J11 4.7uF
C1203 2113741F49 .01uF
C1204 2113740F59 220pF
C1206 2113740L37 62pF
C1207 2113740F07 1.5pF
C1209 2311049A57 10uF
C1210 2113743E20 0.1uF
C1211 2113741F49 .01uF
C1212 2311049A07 1uF
C1213 2113743A23 0.22uF
C1214 2113743E10 .033uF
C1215 2113740C37 6800pF
C1216 2311049J11 4.7uF
C1217 2113741F49 .01uF
C1218 2113743E20 0.1uF
C1219 2311049J11 4.7uF
C1220 2311049J11 4.7uF
C1222 2113740F40 36pF
C1223 2113741F49 .01uF
C1224 2113740F49 82pF
C1225 2113741F49 .01uF
C1227 2113741F49 .01uF
C1229 2113741F49 .01uF
C1230 2113741F49 .01uF
C1231 2113741F49 .01uF
C1250 2311049A09 2.2uF
C1251 2113743E20 0.1uF
C1252 2113743E05 .018uF
C1253 2311049J11 4.7uF
C1254 2113741F49 .01uF
C1306 2113740L23 16pF
C1307 2113740L21 13pF
C1308 2113740F19 4.7pF
Circuit
Ref
Motorola
Part No.
Description
C1311 2113741F49 .01uF
C1312 2113741F49 .01uF
C1313 2113741F49 .01uF
C1314 2113740L21 13pF
C1315 2113740L21 13pF
C1316 2113740F15 3.3pF
C1317 2113743E20 0.1uF
C1318 2113741F49 .01uF
C1319 2113741F49 .01uF
C1320 2113741F49 .01uF
C1321 2113740F17 3.9pF
C1323 2113740L21 13pF
C1325 2113741F49 .01uF
C1326 2113741F49 .01uF
C1333 2113740L26 22pF
C1334 2113740L31 36pF
C1335 2113740F19 4.7pF
C1336 2113743E20 0.1uF
C1338 2113741F49 .01uF
C1339 2113741F49 .01uF
C1340 2113741F49 .01uF
C1341 2113740L31 36pF
C1342 2113740L31 36pF
C1343 2113740F15 3.3pF
C1344 2113741F49 .01uF
C1345 2113743E20 0.1uF
C1346 2113741F49 .01uF
C1347 2113741F49 .01uF
C1348 2113740F17 3.9pF
C1349 2113743E20 0.1uF
C1350 2113740F31 15pF
C1351 2113741F49 .01uF
C1352 2113741F49 .01uF
C1401 2113741A45 .01uF
C1402 2113741A45 .01uF
C1404 2113741A45 .01uF
C1405 2113741A45 .01uF
C1407 2113741A45 .01uF
C1410 2113741M69 0.1uF
C1412 2113740A65 270pF
C1413 2113741A45 .01uF
C1414 2113741A45 .01uF
C1415 2113741M69 0.1uF
C1417 2111078B58 430pF
C1419 2113741A45 .01uF
C1420 2113741A45 .01uF
C1423 2113741A45 .01uF
C1424 2113741A45 .01uF
C1425 2113741W01 1uF
C1426 2113741W01 1uF
C1427 2111078B52 240pF
C1428 2111078B52 240pF
C1429 2111078B52 240pF
C1430 2111078B52 240pF
C1431 2113741A45 .01uF
C1432 2113741W01 1uF
Circuit
Ref
Motorola
Part No.
Description
C1433 2113741W01 1uF
C1434 2113741A45 .01uF
C1435 2113741W01 1uF
C1436 2113741A45 .01uF
C1437 2111078B59 470pF
C1438 2111078B59 470pF
C1439 2111078B59 470pF
C1440 2111078B59 470pF
C1441 2111078B51 220pF
C1442 2111078B44 120pF
C1443 2111078B45 130pF
C1444 2111078B45 130pF
C1446 2180060M28 24pF
C1447 2111078B59 470pF
C1448 2111078B59 470pF
C1449 2180060M44 110pF
C1450 2180060M05 3pF
C1451 2180060M49 180pF
C1452 2180060M28 24pF
C1453 2180060M43 100pF
C1454 2180060M31 33pF
C1455 2180060M24 16pF
C1456 2180060M36 51pF
C1457 2113741A45 .01uF
C1458 2311049C01 10uF
C1459 2311049C01 10uF
C1460 2113743E20 0.1uF
C1461 2113741A45 .01uF
C1462 2311049C01 10uF
C1463 2113928E01 1uF
C1464 2113741A45 .01uF
C1465 2113928E01 1uF
C1466 2113741A45 .01uF
C1467 2113740A51 68pF
C1468 2113741A45 .01uF
C1469 2113741W01 1uF
C1470 2113741W01 1uF
C1471 2113741A45 .01uF
C1472 2113741M69 0.1uF
C1473 2113741M69 0.1uF
C1474 2113741A45 .01uF
C1475 2113741W01 1uF
C1476 2113741M69 0.1uF
C1477 2111078B54 300pF
C1478 2111078B54 300pF
C1479 2111078B51 220pF
C1480 2111078B40 82pF
C1481 2111078B40 82pF
C1482 2113928E01 1uF
C1484 2113741F33 2200pF
C1485 2113741A45 .01uF
C1486 2113741M69 0.1uF
C1501 2113741F33 2200pF
C1502 2113741F33 2200pF
C1503 2113741F33 2200pF
C1504 2113741F33 2200pF
Circuit
Ref
Motorola
Part No.
Description
