Section 3: 3-52 Controller T12 Schematics and Parts Lists (8471224L04)
6881091C63-F
Controller T12 Parts List (8471224L04)
Circuit
Ref
Motorola
Part No.
Description
C0101 2113944C45 CAP CER CHP 100.0PF 50V
5%
C0107 2113945L25 CAP,FXD,1000PF,+5%,-
5%,50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0112 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0121 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0122 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0131 2113944C34 CAP CER CHP 22.0PF 50V 5%
C0132 2113944C34 CAP CER CHP 22.0PF 50V 5%
C0141 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0151 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0201 2313960D07 CAP,FXD,10UF,+10%,-
10%,16V-DC,SM,-55DEG
CMIN,125DEG CMAX,174MA
C0202 2313960D07 CAP,FXD,10UF,+10%,-
10%,16V-DC,SM,-55DEG
CMIN,125DEG CMAX,174MA
C0204 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0212 2313960D07 CAP,FXD,10UF,+10%,-
10%,16V-DC,SM,-55DEG
CMIN,125DEG CMAX,174MA
C0221 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0222 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0223 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0224 2113944C45 CAP CER CHP 100.0PF 50V
5%
C0225 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0226 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0228 2313960B30 CAP,FXD,4.7UF,+10%,-
10%,10V-DC,SM,-55DEG
CMIN,125DEG CMAX,122MA
C0231 2113955D31 CAP,FXD,1UF,+10%,-10%,16V-
DC,1206,X7R,-55DEG
CMIN,125DEG CMAX,P
C0232 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0234 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0235 2113945C04 CAP CER CHP 22,000PF 50V
10%
C0236 2113945C25 CAP,FXD,.033UF,+10%,-
10%,50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMA
C0241 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0243 2113944C45 CAP CER CHP 100.0PF 50V
5%
C0244 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0245 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0246 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0251 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0252 2313960B01 CAP,FXD,1UF,+10%,-10%,16V-
DC,SM,-55DEG CMIN,125DEG
CMAX,87MA,E
C0254 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0255 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0256 2113944C45 CAP CER CHP 100.0PF 50V
5%
C0261 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0262 2113944C43 CAP CER CHP 82.0PF 50V 5%
Circuit
Ref
Motorola
Part No.
Description
C0265 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0267 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0271 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0272 2113945C31 CAP,FXD,.1UF,+10%,-10%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0273 2113945L37 CAP,FXD,3300PF,+5%,-
5%,50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0275 2313960F30 CAP,FXD,47UF,+10%,-
10%,10V-DC,SM,-55DEG
CMIN,125DEG CMAX,303MA
C0276 2113945L25 CAP,FXD,1000PF,+5%,-
5%,50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0277 2113945L25 CAP,FXD,1000PF,+5%,-
5%,50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0278 2113945L25 CAP,FXD,1000PF,+5%,-
5%,50V-DC,0603,X7R,-55DEG
CMIN,125DEG CMAX
C0421 2113944A38 CAP CER CHP 82.0PF 50V 5%
C0422 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0423 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0426 2113945A05 CAP CER CHP 470PF 50V 10%
C0427 2113945A05 CAP CER CHP 470PF 50V 10%
C0428 2113944A38 CAP CER CHP 82.0PF 50V 5%
C0429 2113945A05 CAP CER CHP 470PF 50V 10%
C0430 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0431 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0441 2113945A05 CAP CER CHP 470PF 50V 10%
C0442 2113945A05 CAP CER CHP 470PF 50V 10%
C0445 2113945A05 CAP CER CHP 470PF 50V 10%
C0446 2113945A05 CAP CER CHP 470PF 50V 10%
C0447 2113945A05 CAP CER CHP 470PF 50V 10%
C0448 2113945A05 CAP CER CHP 470PF 50V 10%
C0449 2113945A05 CAP CER CHP 470PF 50V 10%
Circuit
Ref
Motorola
Part No.
Description
C0470 2113945A05 CAP CER CHP 470PF 50V 10%
C0471 2113944A38 CAP CER CHP 82.0PF 50V 5%
C0472 2113944A38 CAP CER CHP 82.0PF 50V 5%
C0473 2113944A38 CAP CER CHP 82.0PF 50V 5%
C0474 2113945A05 CAP CER CHP 470PF 50V 10%
C0476 2113945A05 CAP CER CHP 470PF 50V 10%
C0477 2113945A05 CAP CER CHP 470PF 50V 10%
C0478 2113945A05 CAP CER CHP 470PF 50V 10%
C0482 2113945A05 CAP CER CHP 470PF 50V 10%
C0483 2113945A05 CAP CER CHP 470PF 50V 10%
C0484 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0485 2113945A05 CAP CER CHP 470PF 50V 10%
C0486 2113945A05 CAP CER CHP 470PF 50V 10%
C0487 2113945A05 CAP CER CHP 470PF 50V 10%
C0488 2113945A05 CAP CER CHP 470PF 50V 10%
C0490 2113945A05 CAP CER CHP 470PF 50V 10%
C0491 2113945A05 CAP CER CHP 470PF 50V 10%
C0492 2113945A05 CAP CER CHP 470PF 50V 10%
C0493 2113945A05 CAP CER CHP 470PF 50V 10%
C0494 2113945A05 CAP CER CHP 470PF 50V 10%
C0495 2113945A05 CAP CER CHP 470PF 50V 10%
C0496 2113945A05 CAP CER CHP 470PF 50V 10%
C0497 2113945A05 CAP CER CHP 470PF 50V 10%
C0499 2113945A05 CAP CER CHP 470PF 50V 10%
C0501 2113945L49 CAP,FXD,.01UF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0502 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0503 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0504 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0505 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0506 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0508 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
C0509 2113945L17 CAP,FXD,470PF,+5%,-5%,50V-
DC,0603,X7R,-55DEG
CMIN,125DEG CMAX,P
Circuit
Ref
Motorola
Part No.
Description
