Motorola CDM1250 Service Manual

Section 11: 1-1
6881091C63-F
Chapter 1
MODEL CHARTS AND TECHNICAL SPECIFICATIONS
1.0 VHF (136–174 MHz) 25–45 W LDMOS Model Charts
1.1 CDM Series Model Chart
CDM Series, VHF (136–174 MHz) 25–45 W LDMOS
Model Description
AAM25KKC9AA1AN CDM750, 136–174 MHz, 25–45 W Conv Pref (LDMOS)
AAM25KKD9AA2AN CDM1250, 136–174 MHz, 25–45 W Conv Pref (LDMOS)
AAM25KKF9AA5AN CDM1550, 136–174 MHz, 25–45 W Conv Pref (LDMOS)
AAM25KKF9DP5AN CDM1550 LS+, 136–174 MHz, 45 W, 16CH
AAM25KKF9DP6AN CDM1550 LS+, 136–174 MHz, 45 W, 160CH w/MDC
Item Description
X GCN6112 Control Head, CDM750
X GCN6113 Control Head, CDM1250
XXX GCN6114 Control Head, CDM1550
XXX IMUD6015 Tanapa, VHF 136–174 MHz, 25–45 W, 12.5/20/25 kHz
XXX IMUD6015_S Replacement Board, VHF 136–174 MHz, 25–45 W, 12.5/20/25 kHz
X PMUD 2078A Tanapa, VHF 136–174 MHz, 45 W 16CH
X PMUD 2079A Tanapa, VHF 136–174 MHz, 45 W 160CH w/MDC
XXXXX HAD4006 Antenna, 136–144 MHz, 1/4 Wave Roof Mount (Mini U)
XXXXX HAD4007 Antenna, 146–150.8 MHz, 1/4 Wave Roof Mount (Mini U)
XXXXX HAD4008 Antenna, 150.8–162 MHz, 1/4 Wave Roof Mount (Mini U)
XXXXX HAD4009 Antenna, 162–174 MHz, 1/4 Wave Roof Mount (Mini U)
XXXXX HAD4014 Antenna, 146–172 MHz, 3 dB Gain Roof Mount (Mini U)
X X X 6881091C54 User Guide, CDM750
X X X 6881091C55 User Guide, CDM1250
X 6881091C56 User Gmuide, CDM1550
X X 6881094C79 User Guide, CDM1550 LS
+

Motorola CDM1250 Specifications

General

Display	Alphanumeric
IP Rating	IP54
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Signaling	PL, DPL, MDC1200, Quick Call II
Operating Temperature	-22°F to +140°F (-30°C to +60°C)
Power Output	VHF: 1-25W; UHF: 1-25W
