Motorola CDM1250 Service Manual

Section 7: 1-1
6881091C63-F
Chapter 1
MODEL CHARTS AND TECHNICAL SPECIFICATIONS
1.0 Low Band Range 1 (29.7–36 MHz) Model Charts
1.1 CDM Series Model Chart
1.2 PRO Series Model Chart
CDM Series, Low Band Range 1 (29.7–36 MHz)
Model Description
AAM25BKC9AA1AN CDM750, 29.7–36 MHz, 40–60 W, 20 kHz
1
AAM25BKD9AA2AN CDM1250, 29.7–36 MHz, 40–60 W, 20 kHz
1
AAM25BKF9AA5AN CDM1550, 29.7–36 MHz, 40–60 W, 20 kHz
1
Item Description
X GCN6112 Control Head, CDM750
X GCN6113 Control Head, CDM1250
X GCN6114 Control Head, CDM1550
XXX
IMUB6000 Tanapa, 29.7–36 MHz, 40–60 W, 20 kHz
1
XXX
IMUB6000_S Replacement Board, 29.7–36 MHz, 40–60 W, 20 kHz
1
XXX RAB4002_RB Antenna, 29.7–36 MHz, 1/4 Wave Base Loaded (Mini U)
X 6881091C54 User Guide, CDM750
X 6881091C55 User Guide, CDM1250
X 6881091C56 User Guide, CDM1550
PRO Series, Low Band Range 1 (29.7–36 MHz)
Model Description
LAM25BKD9AA2AN PRO5100, 29.7–36 MHz, 40–60 W, 20 kHz Ch Sp
1
Item Description
X GCN6113 Control Head, PRO5100
X
IMUB6000 Tanapa, 29.7–36 MHz, 40–60 W, 20 kHz
1
X
IMUB6000_S Replacement Board, 29.7–36 MHz, 40–60 W, 20 kHz
1
X RAB4002_RB Antenna, 29.7–36 MHz, 1/4 Wave Base Loaded (Mini U)
X 6881091C58 User Guide, PRO5100

Motorola CDM1250 Specifications

General

Display	Alphanumeric
IP Rating	IP54
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Signaling	PL, DPL, MDC1200, Quick Call II
Operating Temperature	-22°F to +140°F (-30°C to +60°C)
Power Output	VHF: 1-25W; UHF: 1-25W
