Motorola CDM1250 Service Manual

Section 11: 4-20 VHF (136–174 MHz) 25–45 W LDMOS PCB 8471234L02, Schematics, and Parts Lists
6881091C63-F
VHF PCB 8471234L02 Parts List
Circuit
Ref
Motorola Part
No.
Description
C3000 2113945L37 CAP 3300 PF
C3001 2113944C73 CAP 6.8 PF
C3002 2113944C76 CAP 9.1 PF
C3003 2113945L37 CAP 3300 PF
C3004 2113944C39 CAP 56 PF
C3005 2113944C45 CAP 100 PF
C3006 2113944C39 CAP 56 PF
C3007 2113945L37 CAP 3300 PF
C3008 2113945L25 CAP 1000 PF
C3009 2113945L13 CAP 330 PF
C3010 2113945L13 CAP 330 PF
C3011 2113945L37 CAP 3300 PF
C3012 2113945L25 CAP 1000 PF
C3013 2113944C39 CAP 56 PF
C3014 2113944C74 CAP 7.5 PF
C3015 2113944C39 CAP 56 PF
C3016 2113944C45 CAP 100 PF
C3017 2113944C84 CAP 43 PF
C3019 2113945L25 CAP 1000 PF
C3020 2113945L25 CAP 1000 PF
C3021 2113944C46 CAP 120 PF
C3022 2113945L49 CAP 1 UF
C3025 2113944C19 CAP 3.6 PF
C3026 2113945C31 CAP 0.1 UF
C3027 2113945L49 CAP 1 UF
C3028 2113945L49 CAP 1 UF
C3030 2113945L25 CAP 1000 PF
C3033 2113944C70 CAP 5.1 PF
C3034 2113944C43 CAP 82 PF
C3035 2113944C33 CAP 18 PF
C3036 2113945L25 CAP 1000 PF
C3100 2113945L25 CAP 1000 PF
C3102 2113944C32 CAP 15 PF
C3103 2113944C36 CAP 33 PF
C3104 2113945C31 CAP 0.1 UF
C3110 2113944C61 CAP 0.5 PF
C3111 2113945C31 CAP 0.1 UF
C3112 2113944C36 CAP 33 PF
C3113 2113944C75 CAP 8.2 PF
C3114 2113944C71 CAP 5.6 PF
C3115 2113944C32 CAP 15 PF
C3116 2113945C31 CAP 0.1 UF
C3121 2113945C31 CAP 0.1 UF
C3122 2113945C26 CAP 39 UF
C3123 2113945C26 CAP 39 UF
C3124 2113944M30 CAP 33 PF
C3132 2113945C31 CAP 0.1 UF
C3133 2313960D07 CAP 10 UF
C3134 2113945C31 CAP 0.1 UF
C3135 2113944M30 CAP 33 PF
C3136 2113944C34 CAP 22 PF
C3137 2113945C26 CAP 39 UF
C3139 2113945C31 CAP 0.1 UF
C3140 2113945C31 CAP 0.1 UF
C3141 2113945C31 CAP 0.1 UF
C3142 2113945C31 CAP 0.1 UF
C3143 2113944C46 CAP 120 PF
C3144 2113945C31 CAP 0.1 UF
C3145 2113945C31 CAP 0.1 UF
C3146 2113945L41 CAP 4700 PF
C3147 2113945C31 CAP 0.1 UF
C3151 2113945L49 CAP 1 UF
C3152 2113945L49 CAP 1 UF
C3202 2113945L49 CAP 1 UF
C3203 2113945L49 CAP 1 UF
C3205 2113945L49 CAP 1 UF
C3206 2313960D07 CAP 10 UF
C3208 2113945C31 CAP 0.1 UF
C3209 2113945C31 CAP 0.1 UF
C3210 2313960B28 CAP 2.2 UF
C3211 2113945C31 CAP 0.1 UF
C3212 2113945C04 CAP 22000 PF
C3213 2313960B28 CAP 2.2 UF
C3214 2313960C78 CAP 2.2 UF
C3215 2313960C78 CAP 2.2 UF
C3221 2113945C31 CAP 0.1 UF
C3222 2113945C31 CAP 0.1 UF
C3223 2115358H25 CAP 1 UF
C3225 2113945C31 CAP 0.1 UF
C3226 2113944C75 CAP 8.2 PF
C3227 2113944C45 CAP 100 PF
C3228 2113945C31 CAP 0.1 UF
C3229 2113945C27 CAP 47 UF
C3231 2113945L49 CAP 1 UF
C3232 2113945L49 CAP 1 UF
C3233 2313960B28 CAP 2.2 UF
C3234 2113945C31 CAP 0.1 UF
C3235 2113945L49 CAP 1 UF
C3242 2113944C02 CAP 220 PF
C3243 2113944C02 CAP 220 PF
C3244 2113944C02 CAP 220 PF
C3245 2113944C02 CAP 220 PF
Circuit
Ref
Motorola Part
No.
Description
C3246 2113944C02 CAP 220 PF
C3247 2113944C30 CAP 10 PF
C3251 2113945C31 CAP 0.1 UF
C3252 2113945L25 CAP 1000 PF
C3253 2313960B30 CAP 4.7 UF
C3254 2113945C31 CAP 0.1 UF
C3255 2313960B28 CAP 2.2 UF
C3263 2113945C31 CAP 0.1 UF
C3302 2113944C73 CAP 6.8 PF
C3303 2113945L49 CAP 1 UF
C3306 2113944C70 CAP 5.1 PF
C3311 2113945C04 CAP 22000 PF
C3314 2113944C73 CAP 6.8 PF
C3315 2113944C32 CAP 15 PF
C3316 2113944C18 CAP 3.3 PF
C3317 2113944C36 CAP 33 PF
C3318 2113944C71 CAP 5.6 PF
C3319 2113945L25 CAP 1000 PF
C3324 2113945L49 CAP 1 UF
C3332 2113945C31 CAP 0.1 UF
C3333 2113945C31 CAP 0.1 UF
C3334 2113945C04 CAP 22000 PF
C3335 2113945L49 CAP 1 UF
C3336 2113945L49 CAP 1 UF
C3337 2113945C31 CAP 0.1 UF
C3341 2113945L25 CAP 1000 PF
C3342 2113944M05 CAP 3 PF
C3344 2113944C65 CAP 1.2 PF
C3345 2113944M25 CAP 20 PF
C3346 2113945L49 CAP 1 UF
C3347 2113945L49 CAP 1 UF
C3348 2113945L49 CAP 1 UF
C3351 2113945L49 CAP 1 UF
C3352 2113945C04 CAP 22000 PF
C3355 2113945L49 CAP 1 UF
C3356 2113945C04 CAP 22000 PF
C3357 2113944C74 CAP 7.5 PF
C3361 2113945L25 CAP 1000 PF
C3362 2113944C72 CAP 6.2 PF
C3363 2113944C41 CAP 68 PF
C3364 2113944C31 CAP 12 PF
C3365 2113945L25 CAP 1000 PF
C3400 2113944C04 CAP 330 PF
C3401 2113944C04 CAP 330 PF
C3402 2113945C04 CAP 22UF
C3403 2113944C36 CAP 33 PF
C3404 2113944C36 CAP 33 PF
Circuit
Ref
Motorola Part
No.
Description
C3405 2113944C06 CAP 470 PF
C3406 2113944C06 CAP 470 PF
C3410 2113945C04 CAP 22UF
C3411 2113945C04 CAP 22UF
C3412 2113944C04 CAP 330 PF
C3413 2113945C31 CAP .10 UF
C3414 2113944C04 CAP 330 PF
C3415 2113945C31 CAP .10 UF
C3416 2113944C04 CAP 330 PF
C3417 2113944C38 CAP 47 PF
C3418 2113944C36 CAP 33 PF
C3419 2113944C04 CAP 330 PF
C3420 2113944C04 CAP 330 PF
C3421 2113945G57 CAP 33000 PF
C3422 2113944F04 CAP 330 PF
C3423 2313960C26 CAP 1 UF
C3424 2113944C02 CAP 220 PF
C3425 2113945C25 CAP 33 UF
C3426 2113944C04 CAP 330 PF
C3427 2113945L33 CAP 2200 PF
C3428 2113945L33 CAP 2200 PF
C3431 2111078B43 CAP 110 PF
C3433 2111078B36 CAP 56 PF
C3434 2113945G45 CAP 10000 PF
C3435 2113944F04 CAP 330 PF
C3436 2313960G32 CAP 10 UF
C3437 2113945G57 CAP 33000 PF
C3438 2111078B59 CAP 470 PF
C3439 2111078B59 CAP 470 PF
C3440 2113945L25 CAP 1000 PF
C3451 2113944F07 CAP 1000 PF
C3453 2113944C06 CAP 470 PF
C3466 2113944F07 CAP 1000 PF
C3471 2113945C04 CAP 22UF
C3475 2113944C33 CAP 18 PF
C3476 2111078B47 CAP 150 PF
C3477 2111078B47 CAP 150 PF
C3501 2113945L33 CAP 2200 PF
C3502 2113945L33 CAP 2200 PF
C3503 2113944C06 CAP 470 PF
C3504 2113945L49 CAP 1 UF
C3505 2313960B01 CAP 1 UF
C3506 2113945L33 CAP 2200 PF
C3507 2113944C45 CAP 100 PF
C3508 2113944C06 CAP 470 PF
C3510 2113944C06 CAP 470 PF
C3511 2113945L25 CAP 1000 PF
Circuit
Ref
Motorola Part
No.
Description
