Section 3: 3-10 Controller T2 Schematics and Parts Lists
6881091C63-F
Controller T2 Parts List
Circuit
Ref
Motorola
Part No.
Description
C0101 2113740F51 100pF
C0107 2113741F25 1000pF
C0112 2113743E20 0.1uF
C0121 2113743E20 0.1uF
C0122 2113743E20 0.1uF
C0125 2113743E20 0.1uF
C0131 2113740F35 22pF
C0132 2113740F35 22pF
C0141 2113743E20 0.1uF
C0151 2113741F49 .01uF
C0201 2311049A57 10uF
C0204 2113743E20 0.1uF
C0212 2311049A57 10uF
C0221 2113743E20 0.1uF
C0222 2113743E20 0.1uF
C0223 2113743E20 0.1uF
C0224 2113740F51 100pF
C0225 2113743E20 0.1uF
C0226 2113743E20 0.1uF
C0227 2113743E20 0.1uF
C0231 2113743G24 2.2uF
C0232 2113743E20 0.1uF
C0234 2113743E20 0.1uF
C0235 2113743E07 .022uF
C0236 2113743E10 .033uF
C0241 2113743E20 0.1uF
C0243 2113740F51 100pF
C0244 2113743E20 0.1uF
C0245 2113743E20 0.1uF
C0246 2113741F49 .01uF
C0252 2311049A07 1uF
C0254 2113743E20 0.1uF
C0255 2113743E20 0.1uF
C0261 2113743E20 0.1uF
C0262 2113740F49 82pF
C0265 2113743E20 0.1uF
C0267 2113741F49 .01uF
C0271 2113741F49 .01uF
C0272 2113743E20 0.1uF
C0273 2113741F37 3300pF
C0275 2311049A99 47uF
C0276 2113741F25 1000pF
C0277 2113741F25 1000pF
C0421 2113743N48 82pF
C0422 2113741F17 470pF
C0423 2113741F17 470pF
C0426 2113743L09 470pF
C0427 2113743L09 470pF
C0428 2113743N48 82pF
C0429 2113743L09 470pF
C0430 2113741F17 470pF
C0431 2113741F17 470pF
C0441 2113743L09 470pF
C0442 2113743L09 470pF
C0445 2113743L09 470pF
C0446 2113743L09 470pF
C0447 2113743L09 470pF
C0448 2113743L09 470pF
C0449 2113743L09 470pF
C0470 2113743L09 470pF
C0471 2113743L09 470pF
C0472 2113743L09 470pF
C0473 2113743L09 470pF
C0474 2113743L09 470pF
C0476 2113743L09 470pF
C0477 2113743L09 470pF
C0478 2113743L09 470pF
C0482 2113743L09 470pF
C0483 2113743L09 470pF
C0484 2113741F17 470pF
C0485 2113743L09 470pF
C0486 2113743L09 470pF
C0487 2113743L09 470pF
C0488 2113743L09 470pF
C0490 2113743L09 470pF
Circuit
Ref
Motorola
Part No.
Description
C0491 2113743L09 470pF
C0492 2113743L09 470pF
C0493 2113743L09 470pF
C0494 2113743L09 470pF
C0495 2113743L09 470pF
C0496 2113743L09 470pF
C0497 2113743L09 470pF
C0499 2113743L09 470pF
C0501 2113741F49 .01uF
C0502 2113743L09 470pF
C0503 2113743L09 470pF
C0504 2113743L09 470pF
C0505 2113743L09 470pF
C0506 2113743L09 470pF
C0508 2113743L09 470pF
C0509 2113743L09 470pF
C0510 2113741F17 470pF
C0511 2113743L09 470pF
C0512 2113743L09 470pF
C0513 2113741F17 470pF
C0514 2113743L09 470pF
C0515 2113743L09 470pF
C0516 2113741F49 .01uF
C0517 2113743N48 82pF
C0518 2113743L09 470pF
C0541 2311049A05 0.47uF
C0542 2311049A99 47uF
C0591 2113743E20 0.1uF
C0592 2113743E20 0.1uF
C0593 2113743E20 0.1uF
C0601 2113741F17 470pF
C0603 2380090M24 10uF
C0611 2311049C06 22uF
C0612 2113743E20 0.1uF
C0622 2311049A99 47uF
C0641 2113741F17 470pF
C0644 2311049A97 33uF
C0645 2113743E20 0.1uF
Circuit
Ref
Motorola
Part No.
Description
C0652 2311049A97 33uF
C0654 2311049A57 10uF
C0655 2113743E20 0.1uF
C0661 2311049C05 47uF
C0662 2113741F49 .01uF
C0663 2113743E20 0.1uF
C0671 2113743E20 0.1uF
C0681 2113743E20 0.1uF
D0101 4880236E05 Chip Schottky
D0151 4813833C02 DUAL SOT MMBD6100
D0179 4813833C02 DUAL SOT MMBD6100
D0621 4813833C02 DUAL SOT MMBD6100
D0651 4813833C02 DUAL SOT MMBD6100
D0660 4813833C02 DUAL SOT MMBD6100
D0661 4813833C02 DUAL SOT MMBD6100
E0271 2484657R01 Ferrite Bead
E0272 2484657R01 Ferrite Bead
E0631 2484657R01 Ferrite Bead
J0401 0902636Y02 CONN FLEX 12 PIN
J0451 0902636Y01 CONN FLEX SIDE ENTRY
J0501 0986105B01 CONN SMD 20 PIN
J0551 0905505Y04 CONN ZIF HORIZONTAL
J0601 0986165B01 DC PWR CONN
Q0110 4880048M01 NPN DIG 47k/47k
Q0151 4880048M01 NPN DIG 47k/47k
Q0171 4880048M01 NPN DIG 47k/47k
Q0173 4880052M01 NPN DRLNGTN MXTA
Q0177 4880048M01 NPN DIG 47k/47k
Q0181 4880048M01 NPN DIG 47k/47k
Q0183 4880048M01 NPN DIG 47k/47k
Q0185 4880048M01 NPN DIG 47k/47k
Q0271 4813824A10 NPN 40V .2A
Q0641 4880048M01 NPN DIG 47k/47k
Q0661 4805921T02 DUAL ROHM FMC2 RH
Q0662 4813824A10 NPN 40V .2A B=50-150
Q0663 4880048M01 NPN DIG 47k/47k
Q0681 4880052M01 NPN DRLNGTN MXTA
R0101 0662057A73 10K 1/16W 5%
Circuit
Ref
Motorola
Part No.
Description
