Motorola CDM1250 Service Manual

Section 7: 1-4 Technical Specifications
6881091C63-F
4.0 Technical Specifications
Data is specified for +25°C unless otherwise stated.
General Specifications
Channel Capacity
CDM750
CDM1250/PRO5100
CDM1550
4
64
128
Power Supply 13.2 Vdc (10.8 – 15.6 Vdc)
Dimensions: H x W x D (in./mm)
CDM750
CDM1250/PRO5100/CDM1550
Depth excludes knobs
40–60 W:
2.32 in. x 6.93 in. x 9.48 in. (59 mm x 176 mm x 241 mm)
2.4 in. x 7.05 in. x 9.84 in. (61 mm x 179 mm x 250 mm)
Add 0.35 in. (9mm) for Volume Knob
Weight (All CDM and PRO models) 4.55 lb. (2064 g)
Sealing: Withstands rain testing per
MIL STD 810 C/D/E and IP54
Shock and Vibration: Protection provided via impact
resistant housing exceeding MIL STD 810-C/D/E
Dust, Salt & Fog Protection provided via environment resistant housing
exceeding MIL STD 810 C/D/E

Motorola CDM1250 Specifications

General

Display	Alphanumeric
IP Rating	IP54
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Signaling	PL, DPL, MDC1200, Quick Call II
Operating Temperature	-22°F to +140°F (-30°C to +60°C)
Power Output	VHF: 1-25W; UHF: 1-25W
