Motorola CDM1250 Service Manual

Section 5: 4-16 UHF Band 1 (403–470 MHz) 1–25 W PCB 8485670Z02, Schematics, and Parts Lists
6881091C63-F
UHF B1 1–25 W PCB 8485670Z02 Parts List
†
Circuit
Ref
Motorola
Part No.
Description
C0223 2113743E20 0.1 uF, 0662057B47 0 Kohm
resistor for LS+ models
C0593 2113743E20 0.1 uF, 0662057B47 0 Kohm
resistor for LS+ models
C3101 2113740F34 20pF
C3102 2113740F31 15pF
C3103 2113740F39 33pF
C3104 2113743E20 100nF
C3110 2113740F37 27pF
C3111 2113743E20 100nF
C3112 2113740F49 82pF
C3114 2113740F33 18pF
C3115 2113740F35 22pF
C3116 2113743E20 100nF
C3121 2113743E20 100nF
C3122 2113743E11 0.039uF
C3123 2113743E11 0.039uF
C3132 2113743E20 100nF
C3133 2311049A57 10uF
C3134 2113743E20 100nF
C3135 2113740L30 33pF
C3136 2113740L29 30pF
C3137 2113743E11 0.039uF
C3139 2113743E20 100nF
C3140 2113743E20 100nF
C3141 2113743E20 100nF
C3142 2113743E20 100nF
C3143 2113740F53 120pF
C3144 2113743E20 100nF
C3145 2113743E20 100nF
C3146 2113741F41 4700pF
C3147 2113743E20 100nF
C3151 2113741F49 10nF
C3152 2113741F49 10nF
C4001 2113740F09 1.8pF
C4002 2113740F39 33pF
C4003 2113740F40 36pF
C4004 2113740F39 33pF
C4005 2113740F39 33pF
C4006 2113740F39 33pF
C4007 2113740F38 30pF
C4008 2113741F25 1000pF
C4009 2113740F27 10pF
C4010 2113741F13 330pF
C4011 2113741F37 3300pF
C4012 2113741F13 330pF
C4013 2113741F37 3300pF
C4014 2113740F51 100pF
C4015 2113740F51 100pF
C4017 2113740F09 1.8pF
C4018 2113740F29 12pF
C4019 2113740F29 12pF
C4020 2113740F39 33pF
C4021 2113740F39 33pF
C4022 2113740F39 33pF
C4023 2113740F29 12pF
C4024 2113741F25 1000pF
C4026 2113740F09 1.8pF
C4027 2113740F09 1.8pF
C4028 2113741F49 10nF
C4029 2113740F09 1.8pF
C4030 2113740F09 1.8pF
C4031 2113740F30 13pF
C4051 2113740F27 10pF
C4052 2113740F49 82pF
C4053 2113740F32 16pF
C4054 2113740F32 16pF
C4061 2113740F63 330pF
C4062 2113743E20 0.1uF
C4064 2113743E20 0.1uF
C4065 2113740F51 100pF
C4067 2113741F37 3300pF
C4068 2113740F51 100pF
C4069 2113741F49 10nF
C4201 2113740F51 100pF
C4202 2113741F49 10nF
C4203 2113741F49 10nF
C4204 2113740F51 100pF
C4205 2113741F49 10nF
C4206 2311049J25 10uF
C4208 2113743E20 100nF
C4209 2113743E20 100nF
C4210 2104993J02 2.2uF
C4211 2113743E20 100nF
C4213 2311049A09 2.2uF
C4214 2311049A09 2.2uF
C4215 2311049A09 2.2uF
C4217 2113741F49 10nF
C4221 2109720D01 0.01uF
C4222 2109720D14 0.1uF
C4224 0882422W23 1uF
C4225 2113741F18 510pF
C4227 2113740F51 100pF
C4230 2104993J02 2.2uF
C4231 2113741F49 10nF
C4232 2113741F49 10nF
C4233 2104993J02 2.2uF
C4234 2113741F49 10nF
C4235 2113741F49 10nF
C4236 2113743E12 0.047uF
Circuit
Ref
Motorola
Part No.
Description
C4242 2113740F51 100pF
C4243 2113740F51 100pF
C4244 2113740F51 100pF
C4245 2113740F51 100pF
C4246 2113740F51 100pF
C4251 2113743E20 100nF
C4252 2113741F25 1000pF
C4253 2311049A56 4.7uF
C4254 2113743E20 100nF
C4255 2113740F51 100pF
C4263 2113743E20 100nF
C4287 2113740F51 100pF
C4289 2113743E20 100nF
C4301 2113740F51 100pF
C4302 2113740L16 8.2pF
C4303 2113740L16 8.2pF
C4304 2113740L08 3.9pF
C4306 2113740L01 2pF
C4307 2113740F51 100pF
C4308 2113743E20 100nF
C4309 2113740F51 100pF
C4311 2113740F51 100pF
C4312 2113740F29 12pF
C4314 2113740F07 1.5pF
C4315 2113740F51 100pF
C4316 2109720D14 0.1uF
C4318 2113743E20 100nF
C4321 2113740F03 1pF
C4324 2113740L03 2.4pF
C4325 2311049A56 4.7uF
C4331 2113740L14 6.8pF
C4335 2113740F51 100pF
C4336 2113743E07 0.022uF
C4337 2113740F44 51pF
C4338 2113740F44 51pF
C4351 2113740F51 100pF
C4352 2113743E20 100nF
C4353 2113743E20 100nF
C4354 2104993J02 2.2uF
C4355 2104993J02 2.2uF
C4361 2113740F51 100pF
C4371 2113743E20 100nF
C4400 2113740F67 470pF
C4401 2113740F51 100pF
C4402 2113741F37 3300pF
C4403 2113740F23 6.8pF
C4404 2113740F51 100pF
C4405 2113740F51 100pF
C4406 2113740F51 100pF
C4407 2113740F51 100pF
C4411 2113741F37 3300pF
Circuit
Ref
Motorola
Part No.
Description
C4412 2113740F51 100pF
C4414 2113740F51 100pF
C4415 2113743E07 0.022uF
C4416 2113740F51 100pF
C4417 2113740F44 51pF
C4419 2113740F33 18pF
C4420 2113740F28 11pF
C4421 2113741A57 33K F
C4422 2113740A55 100pF
C4423 2311049A08 1uF
C4425 2113743E20 100nF
C4426 2113740F51 100pF
C4427 2113741F37 3300pF
C4428 2113741F33 2200pF
C4431 2111078B23 24pF
C4432 2111078B22 22pF
C4434 2113741F49 10nF
C4435 2113740A55 100pF
C4436 2311049A45 10uF
C4437 2113741A57 33K F
C4439 2111078B42 100pF
C4440 2113741F25 1000pF
C4441 2111078B11 8.2pF
C4442 2111078B22 22pF
C4445 2111078B01 3.3pF
C4446 2111078B09 6.8pF
C4447 2111078B01 3.3pF
C4448 2111078B33 43pF
C4449 2111078B29 33pF
C4451 2113741F25 1000pF
C4452 2113740F30 13pF
C4453 2113740F51 100pF
C4454 2111078B11 8.2pF
C4455 2111078B12 9.1pF
C4457 2111078B27 30pF
C4458 2111078B32 39pF
C4471 2113740F51 100pF
C4472 2111078B31 36pF
C4473 2111078B31 36pF
C4474 2113740F29 12pF
C4475 2113740F10 2pF
C4491 2111078B09 6.8pF
C4492 2111078B42 100pF
C4496 2111078B14 11pF
C4497 2111078B07 5.6pF
C4498 2111078B14 11pF
C4501 2113741F33 2200pF
C4502 2113741F33 2200pF
C4503 2113741F33 2.2nF
C4504 2113741F49 10nF
C4505 2311049A07 1uF
Circuit
Ref
Motorola
Part No.
Description
