Motorola CDM1250 Service Manual

Section 6: 1-2 Technical Specifications
6881091C63-F
1.2 PRO Series Model Chart
2.0 Technical Specifications
Data is specified for +25°C unless otherwise stated.
PRO Series, UHF Band 2 (450–527 MHz) 1–25 W
Model Description
LAM25SHC9AA1AN PRO3100, 450–527 MHz, 1–25 W, 12.5/20/25 kHz Ch Sp
LAM25SHD9AA2AN PRO5100, 450–527 MHz, 1–25 W, 12.5/20/25 kHz Ch Sp
LAM25SHF9AA5AN PRO7100, 450–527 MHz, 1–25 W, 12.5/20/25 kHz Ch Sp
Item Description
X GCN6112 Control Head, PRO3100
X GCN6113 Control Head, PRO5100
X GCN6114 Control Head, PRO7100
XXX IMUE6028 Tanapa, UHF 450–527 MHz, 1–25 W, 12.5/20/25 kHz
XXX IMUE6028_S Replacement Board, UHF 450–527 MHz, 1–25 W,
12.5/20/25 kHz
XXX HAE4003_R Antenna, 450–470 MHz, 1/4 Wave Roof Mount (Mini U)
XXX HAE4011_R Antenna, 450–470 MHz, 3.5dB Gain Roof Mount (Mini U)
XXX HAE4012_ Antenna, 470–494 MHz, 3.5dB Gain Roof Mount (Mini-U)
X 6881091C57 User Guide, PRO3100
X 6881091C58 User Guide, PRO5100
X 6881091C59 User Guide, PRO7100
General Specifications
Channel Capacity
CDM750/PRO3100
CDM1250/PRO5100
CDM1550 Series/PRO7100
4
64
128
Power Supply 13.2 Vdc (10.8 – 15.6 Vdc)
Dimensions: H x W x D (in./mm)
CDM750/PRO3100
CDM1250/PRO5100 and
CDM1550 Series/PRO7100
Depth excludes knobs
1 – 25 W:
2.2 in. x 6.93 in. x 6.97 in. (56 mm x 176 mm x 177 mm)
2.34 in. x 7.05 in. x 7.32 in. (59 mm x 179 mm x 186 mm)
Add 0.35 in. (9mm) for Volume Knob
Weight (All CDM and PRO models) 3.15 lb. (1430 g)
Sealing: Withstands rain testing per
MIL STD 810 C/D /E and IP54
Shock and Vibration: Protection provided via impact
resistant housing exceeding MIL STD 810-C/D /E
Dust, Salt & Fog Protection provided via environment resistant housing
exceeding MIL STD 810 C/D /E

Motorola CDM1250 Specifications

General

Display	Alphanumeric
IP Rating	IP54
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Signaling	PL, DPL, MDC1200, Quick Call II
Operating Temperature	-22°F to +140°F (-30°C to +60°C)
Power Output	VHF: 1-25W; UHF: 1-25W
