Motorola CDM1250 Service Manual

Section 4: 1-2 Technical Specifications
6881091C63-F
1.2 PRO Series Model Chart
2.0 Technical Specifications
Data is specified for +25°C unless otherwise stated.
PRO Series, VHF (136–174 MHz) 1–25W
Model Description
LAM25KHC9AA1AN PRO3100, 136–174 MHz, 1–25W, 12.5/20/25 kHz Ch Sp
LAM25KHD9AA2AN PRO5100, 136–174 MHz, 1–25W, 12.5/20/25 kHz Ch Sp
LAM25KHF9AA5AN PRO7100, 136–174 MHz, 1–25W, 12.5/20/25 kHz Ch Sp
Item Description
X GCN6112 Control Head, PRO3100
X GCN6113 Control Head, PRO5100
X GCN6114 Control Head, PRO7100
XXX IMUD6014 Tanapa, VHF 136–174 MHz, 1–25W, 12.5/20/25 kHz
XXX IMUD6014_S Replacement Board, VHF 136–174 MHz, 1–25W, 12.5/20/25 kHz
XXX HAD4006 Antenna, 136–144 MHz, 1/4 Wave Roof Mount (Mini U)
XXX HAD4007 Antenna, 146–150.8 MHz, 1/4 Wave Roof Mount (Mini U)
XXX HAD4008 Antenna, 150.8–162 MHz, 1/4 Wave Roof Mount (Mini U)
XXX HAD4009 Antenna, 162–174 MHz, 1/4 Wave Roof Mount (Mini U)
XXX HAD4014 Antenna, 146–172 MHz, 3dB Gain Roof Mount (Mini U)
X 6881091C57 User Guide, PRO3100
X 6881091C58 User Guide, PRO5100
X 6881091C59 User Guide, PRO7100
General Specifications
Channel Capacity
CDM750/PRO3100
CDM1250/PRO5100
CDM1550/PRO7100
4
64
128
Power Supply 13.2 Vdc (10.8 – 15.6 Vdc)
Dimensions: H x W x D (in./mm)
CDM750/PRO3100
CDM1250/PRO5100 and
CDM1550/PRO7100
Depth excludes knobs
1 – 25W:
2.2 in. x 6.93 in. x 6.97 in. (56 mm x 176 mm x 177 mm)
2.34 in. x 7.05 in. x 7.32 in. (59 mm x 179 mm x 186 mm)
Add 0.35 in. (9mm) for Volume Knob
Weight (All CDM and PRO models) 3.15 lb. (1430 g)
Sealing: Withstands rain testing per
MIL STD 810 C/D /E and IP54
Shock and Vibration: Protection provided via impact
resistant housing exceeding MIL STD 810-C/D /E
Dust, Salt & Fog Protection provided via environment resistant housing exceeding
MIL STD 810 C/D /E
