Motorola CDM1250 Service Manual

Section 2: 4-6 Control Head CDM750 / PRO3100 PCB 8486146B07, Schematics, and Parts Lists
6881091C63-F
Control Head PCB 8486146B07 Parts List
†
* Motorola Depot Servicing only
Reference designators with an asterisk indicate
components that are not field-replaceable
because they need to be calibrated with
specialized factory equipment after installation.
Radios in which these parts have been replaced in
the field will be off frequency at temperature
extremes.
†
Replacement boards must be ordered from
RPSO (formerly CCSD and/or AAD) using the
number shown in the model charts in Chapters 4
- 13. Boards are not orderable using the 84-
prefixed number.
Circuit
Ref
Motorola
Part No.
Description
C0802 2113741F17 470pF 50V
C0803 2113741F17 470pF 50V
C0804 2113741F17 470pF 50V
C0805 2113740F49 82pF 5% 50V
C0806 2113741F17 470pF 50V
C0808 2113741F17 470pF 50V
C0810 2113741F17 470pF 50V
C0811 2113741F17 470pF 50V
C0813 2113741F17 470pF 50V
C0815 2113741F17 470pF 50V
C0816 2113741F17 470pF 50V
C0817 2113740F49 82pF 5% 50V
C0818 2113741F17 470pF 50V
C0821 2113741F17 470pF 50V
C0822 2311049A40 TANT CP 2.2uF 10% 10V
C0823 2113741F49 10nF 50V
C0824 2113741F49 10nF 50V
C0831 2311049A42 TANT CP 3.3uF 10% 6V
C0832 2113743E20 100nF 16V
C0833 2113743E20 100nF 16V
C0843 2113741F17 470pF 50V
D0821 4813833C02 DUAL SOT MMBD6100
D0822 4813833C02 DUAL SOT MMBD6100
D0831 4880236E05 DIODE CHIP SCHOTTKY
D0871 4886171B01 LED RED
D0872 4886171B01 LED RED
D0873 4886171B01 LED RED
D0874 4886171B01 LED RED
D0875 4886171B01 LED RED
D0876 4886171B01 LED RED
D0877 4886171B01 LED RED
D0878 4886171B03 LED YELLOW
D0879 4886171B04 LED GREEN
D0881 4886171B04 LED GREEN
D0884 4886171B04 LED GREEN
D0885 4886171B04 LED GREEN
D0886 4886171B04 LED GREEN
D0887 4886171B04 LED GREEN
D0888 4886171B04 LED GREEN
J0801 0902636Y02 CONNECTOR FLEX 12 PIN
J0811 2864287B01 CONN TELCO 10 PIN JACK
P0801 2809926G01 CONN 1.25MM 2PIN SURMT
Q0821 4805921T02 TSTR DUAL ROHM FMC2
RH
Q0822 4880048M01 TSTR NPN DIG 47k/47k
Q0823 4805921T02 TSTR DUAL ROHM FMC2
RH
Q0841 4880048M01 TSTR NPN DIG 47k/47k
Q0843 4880048M01 TSTR NPN DIG 47k/47k
Q0871 4813824A10 TSTR NPN 40V .2A B=50-150
Q0872 4813824A10 TSTR NPN 40V .2A B=50-150
Q0873 4813824A10 TSTR NPN 40V .2A B=50-150
Q0874 4813824A10 TSTR NPN 40V .2A B=50-150
Q0875 4813824A10 TSTR NPN 40V .2A B=50-150
Q0876 4813824A10 TSTR NPN 40V .2A B=50-150
Q0877 4813824A10 TSTR NPN 40V .2A B=50-150
Q0878 4813824A10 TSTR NPN 40V .2A B=50-150
Q0879 4813824A10 TSTR NPN 40V .2A B=50-150
Q0881 4813824A10 TSTR NPN 40V .2A B=50-150
Q0885 4813824A10 TSTR NPN 40V .2A B=50-150
R0810 0662057A76 13k 1/16W 5%
R0811 0662057A90 51k 1/16W 5%
R0812 0662057A09 22 1/16W 5%
R0813 0662057A01 10 1/16W 5%
R0814 0662057A35 270 1/16W 5%
R0815 0662057A76 13k 1/16W 5%
R0816 0662057A90 51k 1/16W 5%
R0821 0662057A73 10k 1/16W 5%
R0822 0662057A76 13K 1/16W 5%
R0823 1805911V02 POT VOL
R0824 0662057A65 4700 1/16W 5%
R0825 0662057A49 1k 1/16W 5%
R0831 0662057B22 1M 1/16W 5%
R0832 0662057A57 2k2 1/16W 5%
R0833 0662057A89 47k 1/16W 5%
R0834 0662057A35 270 1/16W 5%
R0835 0662057A25 100 1/16W 5%
R0836 0662057A73 10k 1/16W 5%
R0837 0662057A85 33k 1/16W 5%
R0838 0662057A73 10k 1/16W 5%
R0841 0662057A73 10k 1/16W 5%
R0842 0662057A89 47k 1/16W 5%
R0843 0662057A57 2.2k 1/16W 5%
R0844 0662057A73 10k 1/16W 5%
R0845 0662057A65 4700 1/16W 5%
R0847 0662057A09 22 1/16W 5%
R0849 0662057A89 47k 1/16W 5%
R0852 0662057A97 100k 1/16W
R0853 0662057A97 100k 1/16W
R0854 0662057A97 100k 1/16W
R0861 0662057A90 51k 1/16W 5%
R0862 0662057A76 13k 1/16W 5%
R0864 0662057A88 43k 1/16W 5%
R0866 0662057A90 51k 1/16W 5%
R0867 0662057A76 13k 1/16W 5%
R0873 0660076A35 270 5 1/8
R0874 0660076A35 270 5 1/8
R0875 0660076A35 270 5 1/8
R0876 0660076A35 270 5 1/8
R0877 0660076A35 270 5 1/8
Circuit
Ref
Motorola
Part No.
Description
R0878 0660076A35 270 5 1/8
R0879 0660076A35 270 5 1/8
R0880 0662057A81 22k 1/16W 5%
R0881 0662057A35 270 1/16W 5%
R0885 0662057A35 270 1/16W 5%
*U0831 5113802A24 IC 68HC11 W/SCI,SPI,A/D
U0832 5113815A02 IC
U0833 4886061B01 CER RESONATOR 8MHZ
CSTCC8.00MG
VR0816 4805656W09 DIODE ZENER QUAD
MMQA20VT1
VR0817 4805656W09 DIODE ZENER QUAD
MMQA20VT1
VR0821 4813830A15 DIODE 5.6V 5% 225mW
VR0822 4813830A15 DIODE 5.6V 5% 225mW
VR0823 4813830A15 DIODE 5.6V 5% 225mW
Circuit
Ref
Motorola
Part No.
Description
